Powder Coatings for Agricultural and Construction Machinery MT-601
Powder Coatings for Agricultural and Construction Machinery MT-601is an outdoor polyester powder coating series specifically developed for agricultural and construction machinery and related equipment. You can rely on MT-601 to deliver stable appearance, strong adhesion, and reliable corrosion resistance for machinery operating in demanding outdoor and industrial environments.
Application
You can apply MT-601 to a wide range of heavy-duty machinery and structural components exposed to outdoor weathering and mechanical stress, including:
-
Construction machinery frames and attachments
-
Logging and forestry machinery components
-
Agricultural machinery housings and supports
-
Mining machinery structures
-
Truck bodies and external metal components
Performance verification is typically conducted on cold-rolled steel panels commonly used in machinery manufacturing. Testing focuses on adhesion, impact resistance, corrosion resistance, humidity resistance, fuel resistance, and artificial weathering in accordance with ISO and ASTM standards.
Parameters
| Item | Specification |
|---|---|
| Product Type | Outdoor polyester powder coating |
| Curing Schedule | 180–200 °C × 10–15 minutes (metal temperature) |
| Application Method | High-voltage electrostatic spraying |
| Recommended Voltage | 60–80 kV |
| Recommended Film Thickness | 60–150 µm |
| Standard Test Substrate | 0.8 mm degreased and derusted cold-rolled steel |
| Test Film Thickness | 60–80 µm |
Coating Performance:
| Property | Test Standard | Performance Requirement |
|---|---|---|
| Adhesion | ISO 2409 | Class 0 |
| Impact Resistance | ISO 6272 | 50 kg·cm, no failure |
| Pencil Hardness | ASTM D3363 | ≥ 1H |
| Bend Resistance | ISO 1519 | ≤ 2 mm |
| Salt Spray Resistance (NSS) | ISO 7253 | ≥ 500 h, rating 10, no blistering, creepage ≤ 2 mm |
| Damp Heat Resistance | ISO 6270 | ≥ 500 h, slight discoloration only, no blistering, rust, or peeling |
| Weathering Resistance (QUV-B313) | ISO 11341 | ≥ 500 h, ΔE ≤ 5, gloss retention ≥ 50 % |
| Fuel Resistance | ISO 2812-1 | 24 h immersion, no surface change |
| Gasoline Resistance | ISO 2812-1 | 24 h immersion, no surface change |
Features
-
You achieve excellent leveling, resulting in a smooth and uniform coating appearance.
-
You benefit from strong adhesion that supports long-term coating stability on steel substrates.
-
You gain reliable salt spray resistance suitable for outdoor and industrial environments.
-
You obtain stable aging resistance, helping maintain color and gloss during service life.
-
You apply a coating system designed for heavy machinery exposed to vibration, impact, and weathering.
Case
We solved a corrosion durability challenge for a construction machinery manufacturer.
The customer required a coating for truck bodies and machinery components that could withstand long-term outdoor exposure, fuel contact, and high humidity. Their previous coating system showed edge corrosion and gloss loss after extended service.
We recommended MT-601 and supported the customer in optimizing curing conditions and film thickness control. After implementation, laboratory evaluations showed improved adhesion, stable salt spray performance, and consistent appearance after artificial weathering and damp heat testing conducted under international standards. This helped the customer reduce coating-related maintenance and improve equipment durability.
