Transparent powder coating

WA:+86 132 6275 2056

WEB: std-coatings.com

Introduction

Transparent powder coatings are prepared by mixing carefully selected raw materials, including resins, curing agents, and additives. The resulting transparent powder coatings offer excellent economic and social benefits and have a broad market potential.

Application

Transparent powder coating is suitable as a topcoat for metal objects, providing excellent protection and decorative effects. Examples include metal furniture, hardware, bicycles, door handles, and handicrafts. It is also suitable as a protective topcoat for metallic powder coatings. Furthermore, it is suitable for automotive exterior parts, car wheels, interior and exterior paints, architectural coatings, interior and exterior metal components, and gardening equipment.

Features

ItemSpecification
Chemical Type Epoxy/Polyester or Pure Polyester Type
Appearance Flat
Curing Condition (Workpiece Temperature) 200℃ / 10min; improper curing may cause loss of color, gloss, and coating performance
Gloss Depends on specific product
Storage Condition Sealed and stored in a dry, cool place below 30℃
Shelf Life 6 months (<30℃), 12 months (<25℃)
Packaging Specification 25kg/carton

Technical indicators

Note: Substrate and pretreatment: Mechanical performance tests were conducted using 0.6mm thick degreased cold-rolled steel plates; corrosion and aging resistance tests were conducted using 0.6mm thick zinc phosphated steel plates or chromated aluminum plates.
• Film thickness: 60-80μm • Curing conditions: 200℃/10min (workpiece temperature)

ItemIndexTest Standard
Bending Passed, curvature diameter 6mm ASTM D522
Passed, curvature diameter 4mm GB/T 1731
Dry Adhesion Passed, result 5B ASTM D3359
Passed, result Grade 0 ISO 2409
Cupping Test Passed, 6mm, no cracking/peeling ISO1520
Passed, 6mm, no cracking/peeling GB/T 9753
Impact Resistance (Direct Impact) ≥50kg·cm ASTM D2794
≥50kg·cm GB/T 1732
Pencil Hardness ≥H ASTM D3363
≥H GB/T 6739
Chemical Resistance Good (tested with general acids, alkalis, oils at room temperature) /
Water Mist Resistance Passed, 1000h, no blistering or loss of gloss ASTM D1735
Water Immersion Resistance Passed, 24h, no blistering or loss of gloss ASTM D870
Neutral Salt Spray Passed, 250h, no blistering or peeling ISO 9227

Construction Reference

Transparent powder coating can be applied using manual or automatic spraying equipment. For best results, automatic spraying equipment is recommended. Unadhered powder can be recycled through a suitable recovery system.
Atomizing air pressure: ~0.7 bar
Primary air pressure: ~0.7 bar
Recommended voltage: 40~90 kV
