Top Pressure SYTL150/7.5-32 Type Vertical Valve Test Bench Top Pressure Vertical Valve Test Bench Valve Pressure Test Bench

Top Pressure Vertical Valve Test Bench

This test bench is designed and manufactured with reference to similar products of Germany and GB4981 stabdard,It is suitable for sealing test of straight-through welded valves and straight- through flange connection valves , before and after installation. It is suitable for shell test, sealing test (low pressure sealing test and high pressure sealing test) and upper seal test (ISO5208) for GB4981, in order to prevent faulty valves from entering work site.

Features: simple operation, safe and reliable, sensitive test.

Valve Nominal Diameter DN

20-150mm( Flange connection valves)

if with special sealing plate ,it can be used to test the welding valve

Maximium Test Pressure PN

Nominal Voltage

Exchange 380V

Rated Power

7KW

Line Voltage

Exchange 220V/24V

Hydraulic oil

N46 hydraulic Oil(provide by user)

The oil temperature is Max 60 degrees centigrade ,Min 5 degrees centigrade

Oil circuit system Pressure

28Mpa max

Test Medium

Water(Allows to add rust inhibitor)

keroseneor other liquid it’s viscosity not higher than water

Test temperature(Envioment Temp)

5 degree centigrade to 40 degree centigrade

Transverse clamping Length scope

0-700mm

Radial distance

380mm

Max Clamping Force

20(T)

Weight

Size

1850×700×1900(mm)

Valve Nominal Diameter DN(mm)

70max

80

90

100

150

Max Test PressurePN(MPa)

26

20

16

Comparision Table of Valve Sealing Pressure and Test Pressure

SYTL 150/7.5-32Valve Test Bench Pressure Comparision Table

Norminal Pressure(MPa)

Test Pressure(MPa)

Norminal Diameter(DN)

Sealing Pressure(MPa)

in

mm

3/4

20

1

25

2

50

2-1/2

65

3

80

4

100

6

150
