Clevis Hangers
Size: 1/2”~12”
Material: Carbon Steel
Dimension: UL 203, MSS SP-58/69 (Type-1)
Surface: Pre-galvanized / electro-galvanized
Application: Non-insulated stationary pipeline
Products Details
What’s the pipe hanger? A pipe hanger is a device or component used to support the gravity load of a system pipe. clevis hangersoffers vertical adjustment and consists of a clevis-style top that bolts to a formed steel bottom strap. Seismic bracket is after seismic reinforcement of building water supply and drainage, fire fighting fittings, heating, ventilation, air conditioning, gas, heat, electricity, communications and other mechanical and electrical engineering facilities, when encountering the seismic fortification intensity of the earthquake in the area, can achieve the reduction of earthquake damage, reduce and as far as possible to prevent the occurrence of secondary disasters, so as to achieve the purpose of reducing casualties and property losses. Electromechanical seismic brackets are various components or devices that limit the displacement of auxiliary mechanical and electrical engineering facilities, control the vibration of the facilities, and transfer the load to the load-bearing structure.
|
Available size |
||
|
Pipe size |
HangerRod Size (RS) |
Maxrecommend load (N) |
|
1/2″ / DN15 |
3/8″/ M10 |
2710 |
|
3/4″ / DN20 |
3/8″/ M10 |
2710 |
|
1″ / DN25 |
3/8″/ M10 |
3240 |
|
1-1/4″ / DN32 |
3/8″/ M10 |
3240 |
|
1-1/2″ / DN40 |
3/8″/ M10 |
3240 |
|
2″ / DN50 |
3/8″/ M10 |
3240 |
|
2-1/2″ / DN65 |
1/2″/ M12 |
6000 |
|
3″ / DN80 |
1/2″/ M12 |
6000 |
|
4″ / DN100 |
5/8″/ M16 |
6360 |
|
5″ / DN125 |
5/8″/ M16 |
6360 |
|
6″ / DN150 |
3/4″/ M20 |
8630 |
|
8″ / DN200 |
3/4″/ M20 |
8890 |
|
10″ / DN250 |
3/4″/ M20 |
16000 |
|
12″ / DN300 |
3/4″/ M20 |
16900 |
Send product request
Other supplier products
 |
Steel Press Fittings Coupling | Features: Product Variety: Coupling (DDS Coupling ),Long coupling ,Reducer Coupling Size：DN20-DN50 Material: Carbon Steel Q235,Stainless Workin... |
 |
Multifunctional hydraulic control valve | Features: Size: 2"-24”(DN50-DN600) Material: Ductile iron ASTM A536, 65-45-12 Dimension: ASME B16.42 Connection：ASME B16.1 CLASS 125/250 ... |
 |
Malleable Iron pipe fittings 130 Equal Tee | Features: Code：130 Size: 1/8''-6'' Material: BS EN 1562,EN-GJMB-350-10,KTH350-10 Dimension: BS EN 10242 Thread: ISO 7-1,BS 21,BSPT Pressure R... |
 |
Stainless Steel Nipple | Features: Material ：ASTMA312/A312M Dimensions ：ASTM A733 Threads ：ASME B1.20.1 Schedule ：40/80 PRODUCTS DETAILS: Stainless Steel Nipple... |
 |
Cup Nut Pipe Loop | Size: 1”~8”Material: Carbon SteelDimension: UL 203, MSS SP-58/69 (Type-7)Surface: Pre-galvanized / electro-galvanizedApplication: Non-i... |
Same products
 |
UHMWPE pipe for mining in Australia | Seller: Shandong Yanggu Dragon New Material Co Ltd | UHMWPE pipe for mining in Australia Discover the Ultimate Solution: Are you ready to eleva... |
 |
20543RW Interlock One Piece Fittings | Seller: Hebei Zhongke Huatai Fluid Technology Co., Ltd | 20543RWInterlock One Piece Fittings Product Introduction H20543RW HT H... |
 |
20411RW One Piece Fittings | Seller: Hebei Zhongke Huatai Fluid Technology Co., Ltd | HT HydraulicsSince 1987 Hydraulic Hose Fitting -One Piece Fittings Metric Female 24° Cone O-... |
 |
26713RW Interlock One Piece Hose Fittings | Seller: Hebei Zhongke Huatai Fluid Technology Co., Ltd | HT Hydraulics Since 1987 Hydraulic Hose Fitting-Interlock One Piece Fittings JIC FEMALE 74° ... |
|
|
