High frequency power supply rectifier module 220VAC input 24V20A output natural cooling method for telecom communication

Model No.:TH24V20A-220
1.Cooling method:natural cooling
2.Net weight:4.5kG
3.Dimension:179mm*109mm*260mm(H*W*D,exclude plate)
4.Working temperature:-10degree centigrade~40degree centigrade
5.AC input voltage:220VDC(-10%~30%)/220VAC±15%
6.DC output voltage:21-29VDC
7.DC output current:20A
8.Efficiency:≥91%
9.Voltage stabilization accuracy:≤±0.6%
10.Ripple:≤200mV
11.Noise:≤55dB
12.Current sharing imbalance for modules in parallel:≤±3%
13.Protocol & Interface: TH or Modbus/RS485
