5W 3KVAC Isolation Wide Input AC/DC Converters power supply

TP05AL series is an economical open frame AC/DC switching power supply,The rated output power is 5W
with wide input voltage range, for both AC input and DC input application. High reliability, Low power consumption,
safety isolation .Widely used in industrial control and electrical instrumentation, smart home,etc.

Universal input voltage range	Both for AC and DC input voltage	Low Ripple &Noise
High efficiency, high power density, miniature dimensions	Low power consumption≤50mW
Overheat protection ,Over current protection
International standard Footprint&Pinouts	Industrial product  design	Operating temperature : -40℃ to 70℃


SELECTION GUIDE

Part Number	Input Voltage	Output	Efficiency (Typ. )
%	Ripple &Noise mVp-p


( Typ.)

Voltage (VAC)	Voltag(VDC)	Current(A)
Rated	Range values
TP05AL220S03W	220(4:1)	85-305	3.3	1.00	67	50
TP05AL220S05W	220(4:1)	85-305	5	1.00	74	50
TP05AL220S09W	220(4:1)	85-305	9	0.55	76	50
TP05AL220S12W	220(4:1)	85-305	12	0.42	78	50
TP05AL220S15W	220(4:1)	85-305	15	0.33	80	50
TP05AL220S24W	220(4:1)	85-305	24	0.21	82	50
