2 layers LED PCB
Quick Details
Place of Origin: Guangdong, China (Mainland) Brand Name: XingDa
Base Material: PI, PET, PEN, Polyamide Copper Thickness: 1/2 oz min;12 oz max Board Thickness: 0.2mm-6.00 mm(8mil-126mil)
Min. Hole Size: 0.1mm(4mil) Min. Line Width: 0.075mm(3mil)
Min. Line Spacing: 0.1mm4mil) Surface Finishing: Immersion Gold/Au, HASL, OSP,etc.
Warp & Twist:: 0.7%
Hole Positon: +/-0.075mm(3mil) CNC Driling Insulation Resistance: 10Kohm-20Mohm
Conductivity: <50ohm
Test Voltage: 10-300V
ance Control: +/-10%
Different Impendance: +-/10%
Outline Tolerance: 0.125mm(5mil)
CNC Routing;+/-0.15mm(6mil) by Punching Hole Diameter(H): PTH L:+/-0.075mm(3mil);Non-PTH L:+/-0.05mm(2mil)
Conductor Width(W): +/-20% of original artwork PTH L:+/-0.075mm(3mil)
