Single Axis Welding Positioner Head And Tail Frame

This Head And Tail Frame Single Axis Welding Positioner consists of fixing base, rotation head and tail,welding frame, AC servo motor, RV precise reducer, conductive system, protective cover and electrical control system.

Structure Briefs:

TURIN single axis head and tail frameservo positioner consists of fixing base, rotation head and tail,welding frame, AC servo motor, RV precise reducer, conductive system, protective cover and electrical control system.

Single axiswelding positioneris mainly composed by fixingbase, rotation head and tail, welding positioning frame, AC servo motor and precise gearbox, conductive mechanism, protection cover and electrical control system.The fixed base is welded with high quality profiles,after annealing stress and special mechanicaltreatmentso the machining accuracy and the use accuracy are assured. Antirust appearance paint is beautiful and elegant, and the color can be customized.

Therotation head and tailstockisalsowelded with high quality profiles, after annealingandspecial mechanicaltreatmentto provide long term working stability.

:SOT TECH CO.,LTD

The positioning frame is welded by quality profile,after annealingandspecial mechanicaltreatmentto provide the surface finishing and shelf stability. Standard distance bolt holes are set for customer mount workpiece conveniently.

The rotation stability, positioning accuracy and longlife working is assured by using AC servo motor and RV gearbox.

The conductive mechanism is made in brass, which give perfect conduction. The foundation is wholly insulation to protect the servo motor, robot, welding power, etc.

To assure the quality and working stability, we use Omron (Japan) PLC to control the motions, and electrical components are all from well-known brands.

is the official representative of TURIN Robot company in overseas market and all overseas business issues of TURIN Robots will be handled by SOT Robotics. TURIN is a high-tech enterprise, focusing on , small for handling, and high precision for pick and place applications. More information go
