The color fastness automatic grading system
Application Scope
The color fastness automatic grading system is used to evaluate the color fastness of textiles, including color staining fastness and color change fastness. It can also assess products' resistance to friction (dry and wet friction) fastness, light fastness, and other performance characteristics. Traditionally, color fastness grading is performed by trained and experienced graders using standard light source boxes and gray scale equipment.
Applicable Standards
GB/T 39648-2020 ，1S0 105-C06 VS.AATCC 61
Instrument Features
1. Combines LED active lighting and RGB imaging technology to accurately capture the product's color and appearance, enabling digital grading of color fastness.
2. Automatically grades color change fastness, staining fastness, light fastness, and a series of other performance tests such as resistance to friction.
3. Optionally uploads color fastness data to ERP systems, facilitating enterprise product quality management and data sharing.
Technical Specifications
1. Light source: LED array light source
2. Drive mode: Horizontal modulation drive
3. LED lifespan: Greater than 12.000 hours
4. Color input: Color camera measurement
5. Imaging camera: 12-megapixel color camera
6. Input interface: Imaging camera, LED light box
7. Light source type: D65
8. Color rendering index: Ra > 97
9. Light source stability: ±1.5%
10. Other features: 85% light uniformity, no flicker
11. Measurement area size: 400mm × 300mm
12. Compliant international standards: ASTM D1729. ISO 3664. DIN, AATCC, BSI, etc.
13. Software language: Chinese and English
14. Dimensions: 500×540×340mm (W×H×D)
15. Weight: 25kg
