Paper thickness tester
Introduction:
Paper thickness tester is suitable for measuring the thickness of various paper (including toilet paper)， cardboard, corrugated cardboard, tobacco sheet, plastic film and other sheet materials.
Standard:
ISO534. GB/T451.3. GBT24328.2. QB/T1055
Advantages:
Measures Fundamental Property: Accurately quantifies thickness, a key characteristic for material specification and quality control.
Versatile Material Application: Suitable for a wide range of sheet materials beyond just paper and board, including films, foils, and textiles.
Standard Compliant: Designed to meet relevant national and international standards for thickness measurement.
High Accuracy and Precision: Offers high accuracy and fine resolution for reliable measurements, particularly important for thin materials.
Automated Testing: Automatic test completion enhances efficiency and reduces operator influence on results.
Data Processing and Reporting: Integrated statistical functions and printer output facilitate immediate analysis and documentation.
User-Friendly Operation: Touch screen interface simplifies setup and use.
Features:
Chinese touch screen display, friendly man-machine interface operation, automatic completion of the test, with the test data statistical processing function, micro printer output.
Parameters:
Measuring range: (0——5) mm (measuring paper, sheet)， (0——20) mm (measuring cardboard)
Accuracy: ±0.001mm or ±0.5%
Flatness of two measuring surfaces: ≤0.001mm
Test contact area: (2±0.05)cm², (10±0.2)cm²
Contact pressure (can be set arbitrarily) : (0.5-500)kPa, (0.1-100)kPa
Test speed: ≤3mm/s
Weight: About 20kg
Power supply: AC220V, 50Hz
Dimensions: 330×340×350mm
Send product request
