Scott Flex Tester
Product Introduction:
Scott kneading tester is suitable for back and forth kneading resistance of leather, leather and woven materials.
One end of the sample is fixed in the left fixture, the other end is fixed in the right fixture, with a certain stroke and number of times, and the appropriate pressure, the two samples are bent to each other, after a certain number of times, to assess the degree of damage to the sample.
Meet the criteria:
GB/T 8948-2008. JIS L1096. K6404ASO M403
Product Advantages:
Measures Key Durability Property: Evaluates the resistance of flexible materials to fatigue and damage caused by repeated flexing or kneading.
Standard Compliant: Designed to meet national and international standards for flexing or kneading resistance testing of leather, textiles, and similar materials.
Versatile Material Testing: Applicable to a range of flexible sheet materials like natural leather, artificial leather, and woven fabrics.
Provides Objective Assessment: Allows for assessment of damage after a set number of cycles or determination of cycles to failure.
Controllable Test Parameters: Enables setting and controlling the flexing stroke, number of cycles, and applied pressure.
Product Features:
Based on the provided introduction and the typical design of Scott-type flexing testers for flexible materials:
Clamping fixtures located at both ends to securely hold the test specimen.
Mechanism that moves the clamping fixtures to induce a controlled back-and-forth bending or kneading action on the sample.
Controllable flexing stroke or bending angle.
Counter to record the number of flexing cycles performed.
System for applying a specified pressure to the sample during flexing (as mentioned, "appropriate pressure").
Likely includes multiple testing stations to test several samples simultaneously, increasing efficiency.
Robust construction suitable for repetitive flexing tests.
Product Configuration:
A. One standard specimen laser cutter
B. One set of product manuals and one CNAS-accredited calibration reportProduct Specifications:
4. Specimen Load: 200-2000g (brick-to-brick)
B. Clamp Width: 45mm
C. Clamp Spacing: ~50m (adjustable)
D. Test Speed: 120 times/in
E. Test Stroke: ~60mm (adjustable)
F. Power Supply Voltage: 220V 50Hz
G. Machine Dimensions: 450x370x500mm
H. Machine Weight: 60kg
