Five Fingering Scraper
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
Standards
China: GB/T 2918, GB/T 6151, GB/T 8424.3
Europe: PV3952, BMW GS97034-2, BMW GS97034-9
North America: GMN 3943-2003, FLTM BN 108-13, STD1024-3113, GMW 14698-A, GMW 14688
Product Advantages
Universal Applicability: Designed for scratch resistance testing of automotive interior materials including plastics, rubber, leather, fabrics, coatings, and non-composite substrates.
Precision Engineering: Achieves linear motion accuracy via a high-precision servo motor and ball screw drive system, ensuring repeatable test results.
Modular Flexibility: Interchangeable tungsten carbide scraping tools and adjustable weight systems (0–100N load range) adapt to varying test protocols.
Durability: Corrosion-resistant aluminum and stainless steel construction withstands harsh laboratory environments.
User-Centric Design: Intuitive embedded system with bilingual (English/Chinese) touchscreen interface simplifies operation for global teams.
Product Features
Integrated Drive System
Combines a robust drive motor, scraper assembly, and sample fixation unit for stable testing.
Scraper assembly includes a bracket-mounted tungsten carbide tool, precision weight support bar, and load adjustment mechanism.
Versatile Testing Capabilities
Supports linear motion scratch testing under variable loads (10–200mm/s adjustable speed).
Compatible with smooth/textured materials, hard coatings, liquid metals, and soft substrates like carpets.
Advanced Control System
Embedded system automates testing sequences via a 7-inch touchscreen.
Precision servo motor ensures ±0.1mm positioning accuracy.
Customizable Test Configurations
Optional multi-finger scratch heads (1mm, 5mm, 10mm diameters) for standardized or custom testing.
Manual/automatic mode selection with real-time data logging.
Ergonomic Design
Compact footprint (550mm × 400mm × 300mm) and lightweight build (28kg) for easy lab deployment.
Customizable dimensions and specifications available per client requirements.
Technical Parameters
| Parameter | Specification |
|---|---|
| Test Load Range | 0–100N (adjustable in 1N increments) |
| Scratch Speed | 10–200mm/s (programmable) |
| Scratch Head Options | 1mm, 5mm, 10mm tungsten carbide |
| Power Supply | 220V/50Hz (110V optional) |
| Control Interface | 7-inch color touchscreen (bilingual) |
| Instrument Dimensions | 550mm (L) × 400mm (W) × 300mm (H) |
| Net Weight | 28kg |
| Compliance Standards | Over 15 global automotive norms |
