Reciprocating Wear Tester
Standards
ASTM F2496: Scratch hardness and adhesion testing for prints/coatings.
ISO 1518-1 & -2: Scratch resistance determination for paints/varnishes (constant/variable loading).
GME 60248: Scratch resistance for automotive interiors and textiles.
D44 1221: Abrasion resistance for fluff surface materials.
D14 1055-2004 & D42 : Wear resistance for organic coatings and plastic parts.
Product Advantages
Dual-Station Efficiency: Simultaneous testing on two independent workstations accelerates workflow and reduces downtime.
Versatile Applications: Ideal for coatings, plastics, automotive interiors, fabrics, and electronic components.
Precision Control: Adjustable stroke (6–120mm), speed (1–100 cycles/min), and pressure (1N–24N) ensure tailored testing.
User-Friendly Interface: LCD screen with real-time parameter display and programmable settings for speed, cycles, and stroke.
Modular Design: Interchangeable friction heads (CS-10, H-18) and weights accommodate diverse testing requirements.
Lever-Balanced Accuracy: Maintains consistent surface load via counterweight-equipped test arms, ensuring repeatability.
Adjustable Height: Abrasive/load rack adapts to samples of varying thicknesses for universal compatibility.
Product Features
Dual Testing Stations: Independent operation with shared control panel for parallel sample evaluation.
LCD Control System: Intuitive interface for setting cycles (1–999,999), stroke length, and speed; displays real-time progress.
Lever-Balance Mechanism: Precision-engineered test arms with adjustable weights (1N, 2N, 2.5N, 5N, 10N, 24N) for ASTM/ISO compliance.
Interchangeable Friction Heads: Includes semicircular (R18) and flat abrasion heads for material-specific wear simulation.
Height-Adjustable Rack: Accommodates samples up to 120mm thick with easy-to-use locking mechanisms.
Comprehensive Kit: Includes brush, sandpaper, stainless-steel abrasive fixings, and spare parts for seamless maintenance.
Technical Parameters
| Parameter | Specification |
|---|---|
| Stroke Range | 6–120 mm (adjustable) |
| Speed Range | 1–100 cycles/min (stepless adjustable) |
| Weight Options | 1N, 2N, 2.5N, 5N, 10N, 24N (included) |
| Friction Heads | CS-10, H-18, Φ15 semicircular (R18) |
| Sample Holder | 2 sets (adjustable clamping) |
| Power Supply | 220V, 50Hz, 1A |
| Dimensions | 532 (W) × 471 (D) × 630 (H) mm |
| Net Weight | 48.5 kg |
Send product request
