Foam Indentation Fatigue Testing Machine-QINSUN

Standard

ASTM D3574(Standard Test Methods for Flexible Cellular Materials - Slab, Bonded, and Molded Urethane Foams)

ISO 3385(Flexible Cellular Polymeric Materials - Determination of Fatigue by Constant-Force Pounding)

ISO 2439(Flexible Cellular Polymeric Materials - Determination of Hardness (Indentation Technique))

Product Advantages

Precision Fatigue Testing

High-resolution load cell (±0.01 N accuracy) captures subtle foam deformation, critical for memory foam and polyurethane materials.

Automated Test Cycles

Programmable waveforms simulate decades of real-world usage (e.g., seating, mattresses) in days.

Advanced Material Analytics

AI-powered software predicts compression set, resilience, and fatigue life (S-N curves) automatically.

User-Centric Design

15.6-inch touchscreen interface with multilingual support (English, German, Chinese, Japanese) and one-touch test protocol selection.

Industrial Durability

Corrosion-resistant frame, IP65 enclosure, and anti-vibration feet ensure long-term reliability in demanding labs.

Product Features

Multi-Mode Testing

Constant Force: Applies static load to assess creep resistance.

Cyclic Loading: Varies pressure (1–50 kPa) and frequency (0.1–20 Hz) to replicate dynamic usage.

Temperature Control: -20°C to +80°C chamber for accelerated aging tests.

Real-Time Monitoring

High-speed cameras (1.000 FPS) capture indentation depth and surface deformation.

Data Management

Cloud-compatible software stores 50.000+ test results, generates ISO/ASTM reports, and supports barcode scanning.

Universal Specimen Compatibility

Adjustable clamps accommodate foam samples (100×100×50 mm to 500×500×200 mm).

Technical Parameters

ParameterSpecification
Load Capacity 0–50 kN (±0.01 kN accuracy)
Frequency Range 0.1–20 Hz (adjustable)
Temperature Control -20°C to +80°C (±0.5°C accuracy)
Indentation Depth 0–200 mm (±0.01 mm resolution)
Data Acquisition Rate 100.000 Hz (load/displacement channels)
Power Supply 220V/110V AC, 50/60Hz, 2.8kW
Dimensions (L×W×H) 1.4×1.0×2.0 m
Weight 420 kg
Operating Environment 5–40°C, ≤85% RH (non-condensing)

Accessories Included

Specimen Clamps: Adjustable fixtures for foam blocks (100×100×50 mm to 500×500×200 mm).

Calibration Kit: Load cell, displacement sensor, and NIST-traceable certification.

Safety Gear: Heat-resistant gloves, face shield, and emergency eyewash station.

User Manual & Software: Digital guide (multilingual) + AI analytics platform for fatigue life prediction.

Environmental Chamber: Temperature-controlled enclosure with antifreeze additive.

Ideal For:

Foam manufacturers (memory foam, polyurethane, latex)

Automotive OEMs (seating, headrests, armrests)

Furniture quality control laboratories

Materials science research institutions
