Fogging Tester for Automotive & Textile Materials-QINSUN
Standard
DIN 75201(Determination of the Evaporation Behavior of Materials in Motor Vehicles)
ISO 6452(Rubber- or Plastics-Coated Fabrics — Determination of Fogging Characteristics)
SAE J1756(Determining the Fogging Characteristics of Interior Automotive Materials)
Product Advantages
Precision Fogging Analysis
Dual-mode testing (glass plate and aluminum foil methods) captures both volatile and semi-volatile compounds.
High-Temperature Stability
Temperature-controlled chamber (50–150°C, ±0.5°C accuracy) simulates extreme cabin environments.
Automated Data Collection
Integrated spectrometer (300–1100 nm wavelength range) and AI-powered software analyze fog density in real time.
User-Centric Design
10.1-inch touchscreen interface with multilingual support (English, German, Chinese, Spanish) and one-touch calibration.
Cost-Effective Compliance
Reduces testing time by 40% compared to traditional methods, with ISO/ASTM-compliant reports generated automatically.
Product Features
Testing Modes
Cold Fogging: Simulates low-temperature storage conditions.
Hot Fogging: Replicates high-temperature cabin exposure (e.g., summer heat).
Real-Time Monitoring
High-resolution camera captures fogging patterns every 5 seconds.
Data Management
Cloud-compatible software stores 50.000+ test results and generates DIN/ISO/SAE reports.
Safety Features
Overheat protection, emergency venting, and CE/UL certification for laboratory safety.
Technical Parameters
| Parameter | Specification |
|---|---|
| Temperature Range | 50–150°C (±0.5°C accuracy) |
| Spectrometer Wavelength | 300–1100 nm (±1 nm resolution) |
| Data Acquisition Rate | 10.000 Hz (fog density channel) |
| Chamber Volume | 15 liters (stainless steel interior) |
| Power Supply | 220V/110V AC, 50/60Hz, 1.8kW |
| Dimensions (L×W×H) | 600×500×800 mm |
| Weight | 85 kg |
| Operating Environment | 15–35°C, ≤85% RH (non-condensing) |
Accessories Included
Testing Kits:
2× glass plates (150×100 mm) and 10× aluminum foil sheets.
Calibration Tools:
Temperature sensor, spectrometer reference, and NIST-traceable certification.
Safety Gear:
Heat-resistant gloves, face shield, and fume extraction hose.
User Manual & Software:
Digital guide (multilingual) + AI analytics platform for fogging prediction.
Environmental Chamber:
Temperature-controlled enclosure with corrosion-resistant coating.
Ideal For:
Automotive OEMs (interior trim, dashboard, and seat material testing)
Textile manufacturers (apparel, upholstery, and synthetic fabrics)
Regulatory testing agencies (DIN/ISO/SAE compliance)
Consumer product safety laboratories
Qinsun Instruments Co., LTD is a professional laboratory testing instrument manufacturer in China,Have been focusing on laboratory instrument R&D more than 30 years and have rich industry experience,Based on international testing standards,We are also the instrument supplier for BV SGS laboratory,We provide one-stop solutions for lab instruments,Free Training and Turn-Key Service,Products exported all over the world,Offer 36 month warranty and are a trustworthy partner.
