Seam Fatigue Tester for Textile & Apparel Durability-QINSUN
Standard
ISO 13935-1/2(Textiles – Seam Fatigue Testing for Woven Fabrics)
ASTM D1683(Standard Test Method for Failure in Sewn Seams of Woven Apparel Fabrics)
AATCC 136(Bonding Strength of Fusible Interfacing in Garments)
Product Advantages
Precision Seam Fatigue Analysis
Dual-axis motion system (0–50 mm stroke, 1–5 Hz frequency) replicates real-world bending and stretching.
Universal Material Compatibility
Tests woven, knitted, and technical fabrics, including leather, denim, and coated materials.
Automated Cycle Testing
Programmable cycles (1–999.999 strokes) with automatic failure detection (e.g., seam breakage).
User-Centric Design
7-inch touchscreen interface with multilingual support (English, Spanish, French, Chinese) and one-touch test start.
Modular Clamping System
Quick-release fixtures for flat seams, curved seams, and buttonholes.
Product Features
Testing Modes
Dynamic Stretch: Simulates body movement (e.g., knee bends, elbow flexing).
Cyclic Bending: Replicates folding during storage or washing.
Real-Time Monitoring
High-resolution force sensor (±0.01 N accuracy) and displacement encoder capture seam degradation.
Data Management
Cloud-compatible software stores 100.000+ test results and generates ISO/ASTM/AATCC-compliant reports.
Safety & Compliance
Overload protection, emergency stop, and CE/UL certification for laboratory safety.
Accessories Included
Testing Clamps: 4× universal fixtures for flat seams, curved seams, and buttonholes.
Calibration Kit: Force sensor, displacement encoder, and NIST-traceable certification.
Sample Templates: 10× pre-cut patterns for standard seam types (e.g., jeans, jackets).
User Manual: Multilingual guide (English, Spanish, French, Chinese) with maintenance tips.
Safety Gear: Heat-resistant gloves, face shield, and emergency eyewash station.
Ideal For:
Garment manufacturers (denim, outerwear, sportswear QC)
Textile mills (fabric seam strength validation)
Retail brands (apparel durability testing)
Third-party labs (ISO/ASTM/AATCC certification)
Technical Parameters
| Parameter | Specification |
|---|---|
| Maximum Test Force | 500 N (±0.1% accuracy) |
| Frequency Range | 1–5 Hz (adjustable) |
| Stroke Length | 0–50 mm (±0.05 mm resolution) |
| Test Stations | 2 (expandable to 4) |
| Dimensions (L×W×H) | 600×400×300 mm |
| Weight | 45 kg |
| Operating Environment | 15–35°C, ≤85% RH (non-condensing) |
| Power Supply |
220V/110V AC, 50/60Hz, 300W |
