Snap Button Tester

Produced by: Standard Groups

All supplier products

Get a quote：

Whats/App: +86 185 0176 3615

Web: qinsun-lab.com

Standard

ASTM D7142-2/F963: Standard Consumer Safety Specification for Toy Safety
CFR 1500: Consumer Product Safety Commission (CPSC) Hazardous Substances Act
EN 71 PART1: Safety of Toys – Mechanical and Physical Properties
GB 6675: National Standard for Toy Safety (China)
ISO 8124: Safety of Toys – Migration of Certain Elements
M&P P115A: International Standard for Apparel Fastener Testing

Child Safety First: Specifically designed to prevent button/fastener detachment risks in infant/children’s clothing.
Versatile Testing: Evaluates snap buttons, zippers, hooks, D-rings, decals, and denim fasteners.
Precision Force Control: Imada push-pull gauge applies 17 lbs (7.73 kg) vertical force with 0.1 kg accuracy.
Compliance Assurance: Meets CPSC, EN, and ISO standards, reducing liability for manufacturers.
Manual & Automatic Modes: Rotary flywheel for manual force adjustment or automated testing.
Durable Construction: Stainless steel clamps and anvil ensure long-term reliability.

Dual-Clamp Design: Concave clawless pliers (fastener holder) and bottom fabric pliers (garment holder) ensure secure fixation.
Standardized Testing: Applies 17 lbs (7.73 kg) force for 10 seconds to simulate real-world stress.
Adjustable Anvil: Accommodates diverse fabric thicknesses and fastener sizes.
Multi-Purpose Accessories: Includes clamps for zippers, bow ties, and four-hole fasteners.
No Power Required: Manual operation reduces maintenance costs.
Portable Design: Compact size (40×40×75 cm) and 35 kg weight enable easy relocation.

Parameter	Specification
Test Mode	Manual (Rotary Flywheel)
Max. Test Force	30 kgf (Kilogram-Force)
Standard Pull Force	17 lbs (7.73 kg)
Counterweight	15 lbs (6.8 kg)
Clamp Type	Concave Clawless Pliers + Bottom Fabric Pliers
Force Gauge	Imada Push-Pull Gauge (Digital Display)
Hold Time	10 seconds (Adjustable)
Sample Compatibility	Snap buttons, zippers, hooks, D-rings, decals, denim fasteners
Power Supply	No Power Required
Dimensions (L×W×H)	40 cm × 40 cm × 75 cm
Net Weight	35 kg
