Foam Plastic Horizontal Burning Test Machine
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
Email: serving@qinsun-lab。com
This machine is in accordance with the national standard ISO9772:Determining thecombustion propertiesofthe foamplasticby horizontal combustion test method. For the determination ofdensityof less than 250kg / m³ foam small sample combustion performance levels in a small flame. The PLCand touchscreen can realize the intelligent measuring and providethe convenienceand simple procedure for the experimenter.
It Applies toassessmentof the combustion performance about the burningrate,fireout time, firing range and quality loss.
Standard
ISO 9772
Specification
Ambient temperature: 10 ~ 35 ºC;
Relative humidity: ≤75%;
Powersupply :AC 220V ± 10V 50Hz;
Air purity: ≥95% natural gas, propane;
Technical Parameters
1. The testerconsiststhetest section and controlcomponents foreasy field installation and commissioning.
2. The large observation window is easy to observe the sample combustion state;
3. Advanced industrial appearance and control designing, easy to touch the specimen and burner;
4. Controlling the movement of the burner after closing the door.
5. Bunsen burner is in according with ISO10093:1998 .
Shaft length : 100 ± 10mm,
Inner diameter : 9.5 ± 0.3mm.
The heightof offlame :38 ± 2mm
6. The programmable controller PLC + touch screen for control / testing / computing / data display.
(1) High-voltage automatic ignition
(2) The digital pressure gauge and the touch screen displays the gas pressure and flow.
(3) Burning time is automatically stored and reflected in the test report.
(4) The test time and flame time can be setfrom thetouch screen.
(5) The liquid crystal screen accurately displays the temperature
7. Equipped withsmokeholeandexhaust fan.
8. Import pressure gauge and pressure regulator.
9. Imported gas mass flow meterand needlevalve can accurately control the gas flow.
10. The automatic time record can reserve the test time;
11. The volume oftankis more than 0.5m³;
