ICI Pilling Testing Machine
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
Email: serving@qinsun-lab。com
Product Information
1.Equipped with four pilling Boxes;
2.With the function of forward and reverse running;
3.Optional speeds of 20. 30. 40. 45. 50. 60. 65 and 70 rpm can be chosen arbitrarily;
4.All test parameters are displayed on the LCD delete;
5.Alarm reminding as test ended;
6.Well sealed positions;
7.Automatic pause and caution to safeguard the motor.
Standard
ISO 12945.1. BS 5811. GB/T 4802.3. JIS L1076
Pilling Test Piece Preparation
Rolling case fabric pilling testeris cut from the fabric of size 125mm*125mm, each of them should be marked the reverse side and lengthways side. We need to test both of sides of the sample when the front and back side is not obvious. In addition, we need to cut the same size piece from fabric as compared with the test piece.
Applications
A universal pilling and snagging tester drives system to rapidly repeat pilling or snagging on fabrics to generate normal wear on samples in a fraction of the time.
Provided with unique controller allowing selection between standard and several optional speed settings.
Programmable reversing function at 30 rpm and test cycle definition facilities.
Parameter
| Box Number | 2. 4. 6 | ||
| Control Method | Touch Screen Control | ||
| Speed | 60±2r/min（30~70can be set） | ||
| Box Inside Dimension | （235×235×235）mm | ||
| polyurethane sample tube | Length 140mm，Outer diameter(31.5±1)mm，thickness(3.2±0.5)mm, mass (52.25±1)g，4pcs for a box | ||
| Counter | 1~99999cycles | ||
| ICI pilling test method | GB/T 4802.3. ISO 12945.1. BS 5811. JIS L1076 | ||
| Power | AC 220V 50Hz 120W | ||
| Dimension/Weight(cm/kg) | 82*42*55/40 | 82*42*85/60 |
98*51*120/142 |
