Children\'s Product Comprehensive Force Tester
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
Email: serving@qinsun-lab。com
Applicable Standards
GB/T 31701 - 2015. GB/T 6675 - 2003. GB/T 32599. EN71 - 1. BS 7909. ASTM F963. 16CFR1500.51. GB/T 22704. etc.
Application Scope
The comprehensive force tester for children's products is used for the testing of tensile force, pressure (constant pressure, constant time) and torque (constant pressure, constant time) as stipulated in standards such as children's clothing standards, European toy safety standards, American toy safety standards, and toy safety technical specification standards.
Instrument Features
1. The control panel provides instant access to common test functions (start, stop, return, calibration, reset gauge length and jog).
2. Integrated tension, compression and torsion functions, microcomputer control, electronic sensors, high - precision ball screws, AC servo motor drive, automatic data processing and storage, capable of analyzing the test process, high - precision and fully automated testing.
Technical Parameters
1. Type: Comprehensive force tester for children's products
2. Control system: Mechanical control panel + computer control software
3. Functions: Tensile force, pressure (constant load, constant speed, constant elongation), torque (constant force, constant load time holding, constant angle)
4. Measuring range/accuracy: Tensile force and pressure: 0.1 - 500N, accuracy: 0.01N
5. Torque: 0 - 1N.m, accuracy: 0.002N.m
6. Stroke: >300mm
7. Speed: Tensile force and pressure: 1 - 500mm/min, adjustable
8. Torque: 0.1 - 60rpm, adjustable
9. Power supply: AC220V
