Schopper Abrasion Tester - lab instrument
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
Email: serving@qinsun-lab。com
We are a professional testing instrument manufacturer offering complete laboratory testing solutions. If you need more information or wish to explore our full range of test equipment, please contact us for details and technical support.
Standards
DIN 53863. Part 2: Abrasion test methods for textile fabrics (rotary abrasion test).
GME Standard 60345 & GMW Standard 3283: Industry-specific automotive material testing protocols.
VW/Audi Zentral-Norm PV 3908: Volkswagen/Audi group standard for material durability evaluation.
QC/T 216
Product Advantages
Precision Compliance: Designed to fulfill multiple global automotive standards, ensuring universal applicability.
Versatile Applications: Ideal for evaluating abrasion resistance of automotive interior materials (e.g., fabrics, leather, coated textiles) under tension.
User-Centric Design: Compact structure with intuitive touchscreen controls for manual or automatic operation.
Accurate Measurement: Integrated adjustable arc height device (0–10mm) and load-adjustable system (0.5–25N) for precise testing.
Durability: Robust construction with a stainless-steel test head and corrosion-resistant components for long-term reliability.
Efficiency: Reversible rotation direction every 100 cycles minimizes wear bias and accelerates testing processes.
Product Features
Rotary Abrasion Mechanism: A specimen clamped on a rotating test head (166° taper angle) maintains line contact with an abrasion block, simulating tangential friction.
Modular Clamping System: Obtuse-angle cone chuck and mounting support ensure secure specimen fixation during high-speed rotation (75 revolutions/minute).
Touchscreen Interface: Real-time control panel with programmable cycles, load settings, and rotation reversal triggers.
Arc Height Adjustment: Built-in gauge for measuring sample deformation post-test, critical for assessing material resilience.
Load Customization: Interchangeable weights (50g–1500g) accommodate diverse testing requirements, from delicate fabrics to heavy-duty materials.
Space-Saving Design: Compact dimensions (325×565×560mm) and lightweight build (35kg) optimize laboratory workspace utilization.
Technical Parameters
| Parameter | Specification |
|---|---|
| Revolutions per Minute | 75 rpm |
| Taper Angle | 166° |
| Mounting Head Declination | 7° |
| Specimen Size | 100 cm² |
| Test Area | 50 cm² |
| Arc Height Adjustment | 0–10 mm (manual/automatic) |
| Load Range | 0.5–25 N (adjustable) |
| Standard Weights | 50g, 100g, 250g, 500g, 1000g, 1500g |
| External Dimensions | 325 (W) × 565 (D) × 560 (H) mm |
| Net Weight | 35 kg |
| Power Supply | 115/240V, 50/60Hz |
| Power Consumption | 130W |
