45 Degree Flammability Tester - lab instrument

Application:

45 Degree Flammability Tester is used to determine the burning characteristics of textiles fabric under controlled conditions. This test method covers the evaluation of the flammability test of textile fabrics as they reach the consumer for or from apparel other than children’s sleepwear or protective clothing.

Standard

  • ASTM D1230: Flammability of Apparel Textiles (45° Inclined Method)

  • CFR 16 Part 1610: Flammability of Clothing Textiles (Federal Standard)

  • GB/T 14644: Textiles – Burning Behavior – 45° Test Determination of Flame Spread Rate

  • FTMS 191-5908: Flammability of Textiles (Federal Test Method Standard)

  • CAL TB 117: Flame Resistance of Upholstered Furniture Filling Materials

  • NFPA 702: Field Flame Test for Textiles and Films

Product Advantages

  1. Automated Precision: Built-in control system with automatic ignition, timer (0.1s accuracy), and reset for consistent testing.

  2. Adjustable Flame Control: Standard flame height (16mm) with calibrated burner for reliable results.

  3. Standardized Accessories: U-shaped sample holder (152mm × 38mm), bristle device, and flame gauge ensure compliance.

  4. Multi-Industry Application: Tests textiles, toys, soft furniture, and apparel for flame retardancy.

  5. Data-Driven R&D: Provides quantitative data for material innovation and quality acceptance.

  6. Safety Compliance: Meets ASTM, ISO, and federal standards, reducing export certification barriers.

Product Features

  • 45° Inclined Testing: Simulates real-world flame spread angles for accurate flammability classification.

  • Smart Touch Interface: Integrated printer for real-time report generation and data storage.

  • High-Precision Flow Meter: Ensures stable flame height (16mm ±1mm) and pressure control.

  • Ventilation System: Rear vent holes (φ12.7mm × 11) and top exhaust (φ12.7mm × 16) optimize airflow.

  • Sample Fixation: U-type clamp with knob adjustment for specimen thickness (45° tilt angle).

  • Durable Construction: Stainless steel burner (26# syringe needle) and corrosion-resistant components.

Technical Parameters

ParameterSpecification
Operation Interface Smart Touchscreen (Built-in Printer)
Exhaust Vent (Top) φ12.7 mm × 16
Observation Window Transparent (Lucency)
Rear Vent Holes φ12.7 mm × 11
Standard Flame Height 16 mm (Adjustable)
Sample Holder U-Type, 205 mm × 76 mm (Frame: 152 mm × 38 mm)
Ignition Time 1 s (Adjustable)
Sample Rack Adjustment Knob Control (Thickness Adaptive)
Specimen Tilt Angle 45°
Burner Type 26# Standard Syringe Needle
Burner Dimensions 368 mm (L) × 216 mm (D) × 356 mm (H)
Dimensions (L×W×H) 420 mm × 260 mm × 526 mm
Weight 35 kg
Power Supply AC 220V ±10%, 50Hz
Burn Timer Accuracy ±0.1 s
