AATCC Viewing Board - Test Equipment

Get a quote:

Whats/App: +86 185 0176 3615

Web: qinsun-lab.com

TheRating Observation Boardis an intelligent monitoring system designed for real-time evaluation and visualization of product quality metrics in industrial, educational, or laboratory settings. It integrates sensor data acquisition, AI-driven analytics, and customizable scoring frameworks to streamline inspection processes and improve decision-making accuracy.

Type: Multi-modal evaluation platform

Key Metrics: Defect density, compliance score, process deviation

Display: 10.1-inch touchscreen (1920×1200 resolution)

Connectivity: Wi-Fi 6. Bluetooth 5.2. RS-485

Power: 24V DC, 2A

Compliance Standards

ISO 9001:2015 (Quality management systems)

ASTM E2537 (Data logging specifications)

IEC 62304 (Software for medical devices)

GD&T 2018 (Geometric dimensioning)

Key Features

Multi-Layer Scoring:

Process Layer:Tracks real-time deviation from setpoints

Product Layer:Measures defect size/frequency

System Layer:Monitors equipment health

AI Capabilities:

Automatic anomaly detection (CNN-based)

Dynamic scoring weight adjustment

Predictive failure alerts

Customizable Workflows:

Drag-and-drop scoring template builder

Multi-user role-based access

Audit trail with timestamps

Technical Specifications

ParameterSpecifications
Sampling Rate 1000 Hz (per sensor channel)
Scoring Algorithm ISO 2859-1 based adaptive weighting
Storage Capacity 500.000 records (expandable via SD card)
Response Time
Environmental Range -10°C to 50°C | 5%–95% RH
Dimensions 300×200×50mm (W×H×D)

Applications

Manufacturing:Real-time assembly line inspection

Healthcare:Sterilization process validation

Education:Skill assessment scoring systems

R&D:Experimental data qualification

Standard Operation Workflow:

Setup: Define scoring criteria via web interface

Calibration: Reference sample validation

Monitoring: Live data overlay on process flow

Reporting: Automated PDF/CSV exports

Review: Root cause analysis via historical data
