Comprehensive Engine Oil Filter Test Bench

Application

This test bench is designed for comprehensive evaluation of engine oil filters, including spin-on filters and filter bypass valves. It is suitable for:

Production quality control and factory testing

Research and development of engine oil filters

Verification of filter efficiency, pressure drop, and service life

Testing the performance of bypass elements and blocked filter behavior

The bench measures pressure drop, bypass characteristics, original filtration efficiency, and blocked filter life under controlled flow and temperature conditions.

Standards Compliance

The system is designed to meet the following standards:

JB/T 5088.2—2008 – Internal combustion engine spin-on oil filters

Section 6.2: Pressure drop – flow characteristic test

Section 6.3: Filter bypass element characteristic test

Section 6.6: Original filter efficiency test

Section 6.7: Blocked filter service life test

Notes:

Sections 6.2, 6.3, and 6.7 use CC30 diesel engine oil (temperature controlled below 100°C).

Section 6.6 uses 0# diesel or -10# light diesel at room temperature.

Technical Parameters

Main Test System:

ParameterUnitValue
Flow range L/min 5 … 100
Working medium CC30 diesel engine oil (viscosity 24 mm²/s at 74°C), 0# diesel
Pressure gauge range MPa 0 … 2 (accuracy ±5%)
Medium temperature °C Room temp … 100
Differential pressure measurement kPa 0 … 600
Test oil tank volume L 80 (negotiable)
