Automotive Comfort Air Conditioning Dummy Test System
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
The Automotive Comfort Air Conditioning Dummy Test System is a professional solution designed to evaluate cabin thermal comfort and HVAC performance under various climate and driving conditions.
Developed based on the Chinese 50th-percentile male body dimensions, the dummy accurately simulates real human thermal responses through integrated temperature, humidity, airflow, and radiant heat sensors.
The system supports ISO thermal comfort standards and Berkeley-Zhang thermal sensation models, enabling precise assessment of both local and overall thermal comfort. It is widely used by vehicle manufacturers, research institutes, climate chamber laboratories, and intelligent cabin R&D teams.
Features
1) Human-Realistic Dummy Structure
Designed according to the Chinese 50th-percentile male body size
Multi-joint body structure: neck, shoulder, elbow, wrist, waist, knee, ankle
Easily adjustable sitting and leaning postures to match real cabin scenarios
2) Multi-Point Environmental Monitoring
Integrated temperature, humidity, air velocity, and radiant heat sensors
Captures dynamic and non-uniform cabin environment changes
Suitable for steady-state and transient thermal comfort evaluation
3) Advanced Data Analysis & Thermal Comfort Modeling
Supports PMV-PPD, EHT (ISO 14505-2), and the Berkeley-Zhang model
Measures both local and whole-body thermal sensation and comfort
Data visualization: numeric display, Y-T trend charts, and 3D thermal cloud maps
4) Durable Construction for Extreme Environments
Fabricated with lightweight fiberglass and anti-corrosion materials
Designed for long-term operation in high/low temperature and high-humidity environments
Surface coating prevents fading, deformation, and rust
5) High-Efficiency Controller & Flexible Communication
One controller supports multiple dummies simultaneously
Real-time wired or wireless data transmission
Local data export in CSV format
6) Wide Application Scenarios
Cabin HVAC performance testing
Climate chamber simulations
Intelligent cockpit R&D
Ergonomics and human thermal comfort studies
Benchmarking for automotive OEMs and testing organizations
Send product request
