Xenon lamp aging test chamber
TheXenon lamp aging test chamberis a photoaging tester for large-capacity textile testing. With additional sample light frame, temperature sensor and easy to aging filter. 220 can test 38 samples at the same time, with 150S + double capacity. Large-capacity test box combined with the efficient use of hydropower to make it the most economical air-cooled tester.
Applications:
Weather-Ometer and Fade-Ometer with their advanced digital control systems, represent monumental achievements in applying digital and optical technologies in easy-to-use laboratory weathering instruments. The Series is approved by many OEMs in the textiles, paints & coatings and plastics industries as the exclusive platform to deliver accurate, reproducible and repeatable results for predicting service life. The Series has been certified CE, UL, CSA, ISO and EN compliant.
Standards:
AATCC 16-2004：Color Fastness to Light
AATCC TM169：Weather Resistance of Textiles: Xenon Lamp Exposure
ISO 105-B04：Textiles – Tests for Colour Fastness – Part B04: Colour Fastness to Artificial Weathering: Xenon Arc Fading Lamp Test
M & S C9：Marks & Spencer C9
M & S C9A：Marks & Spencer C9A
GB / T 8427：Textiles – Tests for Colour Fastness – Colour Fastness to Artificial Light: Xenon Arc
Features:
◆Xenon Lamp Cooling System-The Series is equipped with a new,ground-breaking xenon lamp cooling system that dramatically reduces the amount of cooling water used.
◆Rotating Sample Rack-Rotating rack delivers the best exposure uniformity
◆Control system - Enhanced control system can handle complex custom programs and simple preprogrammed test, and simple operation page icon is clear and easy to understand ; Irradiation, temperature, humidity programmable step by step change, to meet the various user test requirements.
◆Intelligent and friendly operating system - intuitive LCD touch interface, full-featured, a variety of languages can be selected; water purity indicator can monitor the input water quality; SmartLight MonitorTM ensures that the lamp is installed correctly.
◆Irradiance closed-loop monitoring and automatic adjustment, can be calibrated by the irradiance calibration device on a regular basis. Radiation calibration device should be CNAS / A2LA / JAB and other international mutual recognition agency certificate. The calibration mechanism of the calibration device shall be certified by ISO 17025.
Parameters:
| Chamber Dimensions | 360×380×140 (D×W×H) mm |
| External Dimensions | Approx. 580×500×600 mm (D×W×H) |
| Lamp Power | 1.8KW |
| Lamp Life | 1200 hours of operation |
| Energy Control Point | @340nm, @420nm, @300～400nm or @300～800nm |
| Irradiance | 0.25～0.38W/m2@340nm |
| 0.45～0.71W/m2@420nm | |
| 20～51W/m2@300～400nm | |
| 500～650W/m2@300～800nm | |
| Blackboard Temperature | 38～89℃ (adjustable) |
| Temperature Fluctuation | ±2℃ |
| Humidity Display | No humidity |
| Spray System | No spraying |
| Sample Tray | Flat plate, 290mm×315mm |
| Inner Liner Material | SUS304# stainless steel plate, corrosion resistant, easy to clean, aesthetically pleasing |
| Display Screen | 7-inch color touch screen HMI |
| Operating Mode | Programmed operation (dark/light cycle mode) or fixed value operation |
| Power Supply | AC220V 50HZ 3.5KW |
