Photovoltaic module outdoor exposure test system
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
The Photovoltaic Module Outdoor Exposure Test System is designed to simulate real-world environmental conditions for accelerated aging and performance evaluation of PV modules. It combines precise temperature, humidity, and solar irradiance control with advanced data acquisition and AI-based diagnostics, enabling rapid assessment of long-term durability, degradation modes, and energy harvesting efficiency.
Application
(1) Accelerated aging and performance testing of photovoltaic (PV) modules
(2) Qualification and type approval for PV modules under IEC 61215 and IEC 61730 standards
(3) Outdoor exposure simulation for desert, tropical, polar, and marine conditions
(4) R&D of solar module materials and encapsulation technologies
(5) Assessment of PID (Potential Induced Degradation), delamination, and hotspot formation
Standards
(1) IEC 61215 – Terrestrial Photovoltaic (PV) Modules: Design Qualification and Type Approval
(2) IEC 61730 – Photovoltaic (PV) Module Safety Qualification
(3) UL 61730 – Safety Standard for Photovoltaic Modules
(4) ISO 9060 – Solar Energy: Classification of Pyranometers
(5) CE Certification – Conformité Européenne
(6) Optional: IEC 60904 series for solar simulator calibration
(7) Optional: UL 1699B – Arc-Fault Detection
Features
Real-World Accelerated Aging: Achieves 10–15 year equivalence within 6 months using IEC-compliant damp heat and UV exposure.
Spectral Matching: AM1.5G filtered solar simulation ensures standardized irradiance.
Multi-Environment Testing: -40°C to +85°C chamber range with ±1°C stability and 95% RH for tropical/marine simulation.
Energy Harvesting Capability: Grid-tied system with MPPT tracking offsets up to 70% of power consumption.
Smart Data Acquisition: 16-channel logging of I-V curves, EL imaging, and thermal mapping.
AI-Powered Diagnostics: Machine learning predicts module degradation, including delamination and hotspots.
Safety Features: UL 1699B-compliant arc-fault detection and dual redundant emergency shutoff circuits.
Product Flexibility: Dual-axis tracker (±60° tilt, ±180° azimuth) for precise solar alignment, modular design expandable from 5 kW to 50 kW.
Parameters
| Parameter | Specification |
|---|---|
| Solar Irradiance | 300–1,200 W/m² (AM1.5G filtered) |
| Temperature Range | -40°C to +85°C (operational) |
| Temperature Deviation | ≤ ±1°C (steady state) |
| Humidity Range | 10%–95% RH (non-condensing) |
| Chamber Volume | 2 m × 3 m × 2.5 m (expandable) |
| Power Supply | 380V/415V, 3-phase, 50/60Hz |
| Dimensions (W×D×H) | 2,500 mm × 3,500 mm × 3,000 mm |
| Weight | 1,200 kg (net) / 1,800 kg (gross) |
