Rupture strength tester
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
The Rupture Strength Tester is designed to evaluate the mechanical pressure resistance and rupture strength of photovoltaic module components under controlled pressurization conditions. The system applies uniform hydraulic or pneumatic pressure to determine the failure threshold of module glass, backsheets, and encapsulation structures, supporting safety qualification and structural reliability assessment of photovoltaic modules.
Application
(1) Rupture strength testing of photovoltaic module front glass
(2) Pressure resistance evaluation of PV module backsheets and encapsulants
(3) Safety verification of single-glass and dual-glass photovoltaic modules
(4) Mechanical integrity assessment under simulated wind and snow loads
(5) Quality control and type approval testing in PV module manufacturing
(6) Failure analysis and material comparison in PV R&D laboratories
Standards
(1) IEC 61730-2 – Photovoltaic (PV) Module Safety Qualification – Requirements for Testing
(2) UL 61730 – Safety Standard for Photovoltaic Modules
(3) CE Certification (Conformité Européenne)
Features
(1) Wide Pressure Capability: Suitable for rupture testing of thin-film, crystalline silicon, and dual-glass PV modules.
(2) High-Resolution Pressure Control: Enables early detection of micro-cracking and progressive structural failure.
(3) Multi-Unit Measurement Interface: Supports kPa, psi, and kg/cm² for international testing requirements.
(4) Enhanced Safety Structure: Reinforced test chamber allows safe observation of specimen rupture.
(5) Automated Test Control: Preset pressure ramp and holding sequences reduce operator variability.
(6) Integrated Data Recording: Pressure–time curves and rupture values stored for traceability and analysis.
(7) Robust Construction: Stainless steel frame ensures long-term stability under repeated high-pressure operation.
Parameters
| Parameter | Specification |
|---|---|
| Pressure Range | 250–5,600 kPa (36–812 psi) |
| Pressure Resolution | 0.01 kg/cm² |
| Holding Pressure | 5 kg/cm² (adjustable) |
| Control Accuracy | ±1% FS (full scale) |
| Air Source Requirement | ≥6 kg/cm² (customer-provided) |
| Power Supply | 220V AC, 50/60Hz, single-phase |
| Dimensions | 560 mm (W) × 470 mm (D) × 550 mm (H) |
| Weight | 60 kg (net) |
