Safety Helmets Wearing Stability Tester

Get a quote:

Whats/App: +86 185 0176 3615

Web: qinsun-lab.com

The Safety Helmets Wearing Stability Tester is designed to evaluate helmet retention and fit under dynamic conditions, simulating real-world head movements and impact scenarios. It provides precise measurement of helmet stability, retention forces, and deformation, ensuring compliance with international and national safety standards. The instrument is suitable for production quality control, R&D, and certification testing of industrial, sports, and cycling helmets.

Application

This tester is suitable for assessing helmet fit stability and retention performance for:

(1) Industrial helmets used in construction, manufacturing, and mining

(2) Cycling helmets for road, mountain, and urban riding

(3) Sports helmets for skating, climbing, skiing, and other high-mobility activities

(4) Motorcycle and E-bike helmets for rider safety certification

(5) R&D of custom helmet designs with adjustable retention systems

Standards

The tester complies with the following standards:

(1) GB 811-2022 – Safety Helmets: General Technical Requirements

(2) GB 24429-2009 – Sports Helmets: Requirements and Test Methods

(3) GB/T 2812 – Safety Helmets: Test Methods

(4) ISO 6220-2 – Industrial Safety Helmets: Fit Stability

(5) CE Certification (Conformité Européenne)

Features

Multi-Standard Compliance: Simulates extreme lateral forces and evaluates retention system integrity.

High-Precision Measurement: 0.1kg load resolution and 0.1N force sensor accuracy for repeatable results.

Dynamic Tilt Testing: 360° tilt mechanism reproduces real-world head movements.

User-Friendly Operation: 7” touchscreen HMI with preloaded GB/T 2812 sequences and real-time force graphs.

Quick-Swap Helmet Clamp: Rapid replacement of helmets for high-throughput labs.

Safety Systems: Dual interlocks and overload protection prevent accidental activation and sensor damage.

Self-Calibrating System: Auto-tare and linearity checks before each test.

Durable Construction: Aircraft-grade aluminum frame and corrosion-resistant sensors ensure long-term reliability.

Parameters

ParameterSpecification
Impact Weight 10.0kg ±0.1kg (stainless steel)
Initial Load 3.0kg ±0.1kg (adjustable)
Release Method Manual lever with safety interlock
Tilt Range 0–360° (1° resolution)
Force Sensor 0–500N range, 0.1N resolution
Data Acquisition 16-bit resolution, 1,000Hz sampling
Power Supply 220V AC, 50/60Hz (single-phase)
Dimensions 800mm (W) × 600mm (D) × 1,500mm (H)
Weight 150 kg (net)
