Filter Media Testing System
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
This system is widely used to test filter media and small filter elements during product development, production monitoring, and quality assurance. It is applicable to cabin air filters, engine air filters, and indoor air filters, and supports testing according to ISO 11155-1, DIN 71460-1, ISO 5011, and ISO 16890. Various versions of the system can be configured to conform to additional international and national standards. Its flexible design allows the use of multiple aerosol types, including SAE dust, NaCl/KCl salts, and DEHS liquid aerosols, to simulate real-world operating conditions and verify filter performance under load.
Standards Compliance
(1) ISO 11155-1: Road vehicles — Air filters for occupants’ compartments — Part 1: particulate filtration test
(2) DIN 71460-1: Road vehicles — Air filters for passenger compartments — Part 1: particulate matter filtration tests
(3) ISO 5011: Air filters for internal combustion engines — Performance testing
(4) ISO 16890: Air filters for general ventilation — Particulate matter efficiency testing
Product Features
(1) Simultaneous measurement of particles in feed gas and clean gas.
(2) Particle size measurement range from 0.2 to 40 µm.
(3) Maximum particle concentration up to 10⁶ particles/cm³ (undiluted).
(4) High repeatability and internationally comparable results.
(5) Compatible with various test aerosols such as SAE coarse powder, NaCl/KCl, and DEHS.
(6) Capable of measuring fraction separation efficiency for load testing with high raw gas concentrations (>1000 mg/m³ ISO Fine, >5000 mg/m³ ISO Coarse).
(7) Flexible filter testing software (FTControl) for automated testing, data collection, and analysis.
(8) Easy operation for trained or untrained personnel, with short setup time.
(9) Mobile setup on casters for convenient relocation.
(10) Low maintenance and reliable operation, reducing overall operating costs.
(11) Verifies the functionality of individual components and the complete system during pre-delivery acceptance and commissioning.
Technical Parameters
| Parameter | Unit | Value |
|---|---|---|
| Measurement range (dimensions) | nm | 10 – 800 (U-SMPS 2050) |
| Volume flow rate | m³/h | 0.48 – 5.76 (pressurized operation) |
| Power supply | V, Hz | 115/230 V, 50/60 Hz |
| External dimensions | mm | 600 × 1800 × 900 (W×H×D) |
| Inflow velocity | cm/s | 1.3 – 16 (other specifications available) |
| Differential pressure measurement | Pa | 0 – 2,500 (others available upon request) |
| Media testing area | cm² | 100 |
| Aerosol type | – | Dust (SAE), Salt (NaCl/KCl), Liquid aerosols (DEHS) |
| Compressed air supply | bar | 6 – 8 |
