Reciprocating Wear Tester

Evaluate the wear resistance of key mechanical components such as engine pistons, gears, and bearings. Predict their service life and performance in actual use, assist in optimizing mechanical designs, and enhance product reliability and durability.

Standards

ASTM Standards: Formulated by the American Society for Testing and Materials (ASTM), standards such as ASTM D6079 are used to evaluate the friction coefficient and anti - wear properties of lubricating oils.

ISO Standards: Standards like ISO 12156 established by the International Organization for Standardization (ISO) are also applicable to these tests.

National Standards: In China, the tests may need to comply with the GB/T series of national standards, which have detailed provisions on testing methods, conditions, data processing, etc.

Industry Standards: Depending on specific application fields and testing requirements, certain industry - specific standards are also involved.

These standards are developed according to the testing requirements for specific materials or application areas.

Feature

The reciprocating wear tester is particularly suitable for testing flat surfaces. With optional accessories, the reciprocating wear tester can be configured to evaluate the relative resistance or sensitivity of material surfaces to physical damage such as abrasion, scratching, gouging, friction, scuffing, and rubbing.

Parameters

Technical ParameterSpecification
The biggest test (kN) 10
Test force measuring range 0.06% ~ 100% of the maximum test force
Test force relative error value ±1%; ±5 N when under 400 N
Test force long stay Error of ±1% FN (per...)
The friction measurement range (N) 0-300
Single-stage infinitely variable speed system (r/min) 200 ~ 3000
Spindle speed error (r/min) 10 mm (note: unit may be incorrect)
The friction load sensor (N) 50
The oil box of stroke (mm) >45
The spindle hole taper 1:7
The heater temperature scope of work (℃) Room temperature to 220
The temperature control range (℃) 2 or less
Special standard ball diameter (Incomplete content)
The spindle motor power (kW) 2.2
Machine spindle control Time control, speed (cycle) control, friction control
Machine appearance size (mm) 1200 * 810 * 810
Testing machine quality (kg) 850
