IULTCS Veslic Leather Abrasion Tester
Get a quote:
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
IULTCS Rubbing Color Fastness Tester, designed to carry out a rub fastness test on the surface of leather to determine the amount of "marring"of the leather surface or the finish and to assess the amount of colour transferring from the sample to the rubbing pad under dry or wet conditions.
The unique design of Iultcs Rub Fastness Tester allows reliable and stable test result.
Impact appearance and construction design offers a good shape and convenient operation, also allows a long life time without repairing.
Equipped with an extension device so samples can be extended at a required rate.Two models of single and double test position are offered.
Standards
IS0 11640 Leather-Tests for colour fastness-colour fastness to cycles of to and fro rubbing
SATRA PM 173 Colour fastness to rubbing-reciprocating method
QB/T 2537 Leather-Tests for colour fastness-colour fastness to cycles of to and fro rubbing
GB/T 20991 7.3 Determination of abrasion resistance of insole
EN ISo20344 7.3 Determination of abrasion resistance of insole
AS/NZS 2210.2 7.3 Determination of abrasion resistance of insole
ISO 17700 Method A To and fro square rubbing finger fastness testing Footwear-test methods for upper components and insocks-colour fastness to rubbing
DIN 4843 Safety footwear safety requirements testing
Features
It owns a compact size for the convenience of movement and placement.
A graduated scale is available on the sample holding platform to faciliate extending the specimen manually in the direction of rubbing.
Compatible with wet and dry tests.
One or two test stations in one machine is available.
A microcomputer controls the machine operation.
Fitted with a digital display to set parameters and indicate running status.
The machine is easy for users to use and maintain.
Parameters
| Parameters | Specification |
|---|---|
| Action by | Linear motion unidirectional grinding brush |
| Test speed | 26 times / min |
| Test area | 200cm², 115.5cm², 111cm² |
| Test load | 88300 ± 40Pa |
| Test stroke (adjustable) | 270mm, 210mm, 150mm |
| Count range | From 1 to 99999 |
| Machine Size (W * D * H) | 600mm × 455mm × 232mm |
