Electronic Rubbing Colour Fastness Tester
Applications
Electronic rubbing colour fastness testeris used to determine the colour fastness of cotton, chemical fiber, blended, other coloured fabrics and leather to dry or wet rubbing. Motorised for frequent use and long run tests. A piece of dyed test cloth and a piece of white cotton cloth are rubbed against each other though the tester in a specific pressure and stroke.
The color fastness of the sample is graded by comparing the coloring of the white cotton with the gray scale. Fitted with digital electronic presettable counter for strokes.
Standards
GB/T 3920-2008：Textiles - Tests for colour fastness - Colour fastness to rubbing
BS 1006 D02:2016：Textiles - Tests for colour fastness - Part D02: Colour fastness to rubbing
ISO 105 X12:2016 :Textiles - Tests for colour fastness - Part X12: Colour fastness to rubbing
AATCC 8-2023 :AATCC Test Method 8: Crocking Resistance: Colorfastness to Rubbing
AATCC 165-2022 :AATCC Test Method 165: Colorfastness to Wet Crocking (Padded)
JIS K6328:2018 :Rubber and plastics - Test method for color transfer by rubbing
Features
Electronic rubbing colour fastness tester is used to determine colour fastness of materials to wet and dry rubbing, suitable for frequent use and long run tests.
A.Diameter of friction head:16mm or 25mm;
B.The weight to produce a loading of 9N;
C.Electric drive, working voltage of 220V;
D.Equipped with electronic counter, could completely simulate the results of manual friction for 10 times, with high reproducibility;
E.The fixed device for the standard crocking cloth;
F.A steel spring clip for rapidly fastening samples;
G.Control mode consists of AATCC, ISO standards, and customized setting;
H.Automatic alarm to remind the test over.
Technical Parameters
| Technical Parameters | Specifications & Applicable Standards |
|---|---|
| Number of Workstations | - 1 workstation (most common, applicable to all standards)- 2 workstations (optional, for parallel testing) |
| Rubbing Head Specifications | - 16mm diameter (solid head): Applicable to GB/T 3920-2008. ISO 105 X12:2016 (basic test)- 19mm diameter (solid head): Applicable to AATCC 8-2023- 32mm diameter (padded head): Applicable to ISO 105 X12:2016 (padded test), AATCC 165-2022 |
| Applied Pressure | - 9N: Applicable to GB/T 3920-2008. ISO 105 X12:2016 (basic head)- 11.1N: Applicable to AATCC 8-2023- 12N: Applicable to ISO 105 X12:2016 (padded head), AATCC 165-2022- 4.9N: Applicable to JIS K6328:2018 |
| Reciprocating Stroke | - 100±2mm: Applicable to GB/T 3920-2008. ISO 105 X12:2016- 102mm: Applicable to AATCC 8-2023- 104±3mm: Applicable to BS 1006 D02:2016 |
| Reciprocating Speed | - 60 cycles/min: Applicable to GB/T 3920-2008. ISO 105 X12:2016- 50 cycles/min: Applicable to BS 1006 D02:2016- 43 cycles/min: Applicable to AATCC 8-2023- 30 cycles/min: Applicable to JIS K6328:2018 |
| Test Sample Dimensions | - 200mm × 50mm: Applicable to GB/T 3920-2008. ISO 105 X12:2016- 150mm × 50mm: Applicable to AATCC 8-2023- 100mm × 50mm: Applicable to JIS K6328:2018 |
| Standard Crocking Cloth Specifications | - Cotton cloth (50mm × 50mm): Conforms to GB/T 7568 (for GB/T 3920), ISO 105-F08 (for ISO 105 X12)- AATCC crock cloth (50mm × 50mm): Conforms to AATCC TM8 (for AATCC 8/165)- Woolen cloth (optional): For specific fabric tests |
| Power Supply | - AC 220V/50Hz (domestic standard)- AC 110V/60Hz (international export standard) |
| Operating Environment | Temperature: 15-30℃; Relative Humidity: 45-75% (consistent with textile test standard atmosphere) |
