Random Tumble Pilling Tester
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
Applications
This instrument is widely used in the following fields:
Testing
Quality inspection
Apparel fabrics and home textiles
Textile manufacturing companies
Fair testing by third-party testing institutions
Standards
GB/T 4802.3: China’s national standard for textile pilling resistance.
BS EN ISO 12945-1: European standard for wool-based textile pilling evaluation.
BS 5811. IWS TM152. NEXT TM19: UK retail and industrial specifications.
M&S P18A/P18B/P21A: Marks & Spencer’s proprietary quality benchmarks.
BS 8479: British standard for fabric snagging resistance.
Features
Modular Test Chambers: 4 dedicated pilling boxes (octagonal) and 2 snagging boxes for comprehensive analysis.
Rapid Mounting Jig: Simplifies sample fixation with quick-release clamps.
Accessories Kit: Includes cork liners, snagging points, and a pilling photograph guide for visual grading.
Motor Safety System: Overload protection and thermal cutoff prevent equipment damage.
Customizable Cycles: Users define test duration and reversal intervals via the LCD interface.
Compact Footprint: Space-saving design with integrated storage for accessories.
Technical Parameters
| Technical Parameters | Specifications |
|---|---|
| Test Mode | Automatic |
| Rotation Direction | Unidirectional / Bidirectional (Reversing) |
| Rotation Speed Options | 20rpm, 30rpm, 40rpm, 45rpm, 50rpm, 60rpm, 65rpm, 70rpm |
| Standard Speed Modes | 1. 60rpm Unidirectional 2. 30rpm Unidirectional 3. 30rpm Bidirectional |
| Working Chamber | 4 Chambers |
| End Alarm | Buzzer |
| Steel Nails Material | Stainless Steel |
| Power Supply | 220V, 50Hz |
| Weight | 75 kg |
| Dimensions |
900mm × 800mm × 1100mm |
