Fabric Down-Proof Impact Tester (Impact Method)
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
Application
This tester is ideal for evaluating all types of down products, including duvets, pillows, jackets, and other feather-filled textiles. By simulating repeated compression impacts, it helps manufacturers ensure the fabric prevents feather leakage and maintains product quality.
Standards
BS EN 12132-2 – Down and feather – Test methods – Impact method
FZ/T 43048-2018 – Down and feather products – Anti-drilling test
QB 1090-1991 – General testing requirements for down products
Feature
(1) Firm and stable steel frame structure ensures durability.
(2) Impact system with two plates: a fixed plate with one impact pin and a movable plate with three pins.
(3) Lower impact plate has three fixed impactors at 120° spacing; pins are 80mm long, 15mm diameter, rounded tip.
(4) Movable plate impact frequency controlled at 35 times/min via crank joystick mechanism.
(5) LED display with preset counter and automatic stop function after set impacts.
(6) Adjustable number of impacts from 1 to 99,999 for flexible testing cycles.
Technical Specifications
| Items | Parameters |
|---|---|
| Inclination angle | 20° |
| Impact frequency | 35 times/min |
| Impact stroke | 500 ± 5 mm |
| Impact needle | Φ15 mm × 80 mm |
| Number of impacts | 1–99,999 (adjustable) |
| Display mode | LED |
| Power supply | AC 220V, 50Hz, 180W |
| Exterior dimensions (L×W×H) | 1240 × 330 × 700 mm |
| Weight | 85 kg |
