MST Medical Compression Stocking Tester
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
The MST Medical Compression Stocking Tester is a professional instrument designed to evaluate the compression performance, elasticity, and durability of medical-grade compression stockings. It ensures compliance with international and domestic healthcare and textile standards by measuring pressure distribution, hysteresis loss, and fabric resilience under repeated stress cycles. The compact design makes it suitable for laboratory and clinical environments.
Applications
The instrument is widely used for quality control of medical compression stockings, research and development of pressure-mapping hosiery, clinical validation of therapeutic compression levels, and forensic evaluation of garment failures.
Standards
(1) ISO 13994 – Medical Compression Garments Standard
(2) AATCC 139 – Textile Elasticity Test Standard
(3) YY/T 0561 – Chinese Medical Hosiery Standard
(4) ISO 17025 – Calibration of Testing and Measuring Equipment
(5) ASTM D 3100 – Standard Test Methods for Stretch and Recovery of Textile Fabrics
(6) EN 13795 – Performance Requirements for Surgical Clothing and Drapes
(7) IEC 60601-1 – Safety Requirements for Medical Electrical Equipment
Features
(1) Dual testing modes: static mode to measure initial compression pressure and dynamic mode simulating walking at 5–120 steps per minute
(2) Pressure gradient mapping from ankle to knee
(3) Hysteresis loss calculation and real-time fabric strain visualization
(4) WiFi data export to HIPAA-compliant platforms
(5) ±0.5–1 mmHg measurement accuracy
(6) 100-cycle fatigue testing capability
(7) Medical-grade silicone clamps (latex-free)
(8) Automated zero-drift compensation
(9) CE and IECEx certified for medical environments
Parameters
| Parameter | Specification |
|---|---|
| Pressure Measurement | Capacitive sensor array, 0.1 mmHg resolution |
| Pressure Range | 15–50 mmHg, adjustable |
| Test Modes | Static pressure (1-minute hold) / Dynamic cyclic loading (10–100 cycles) |
| Elastic Recovery Rate | ≥95% |
| Sample Size | 30×300 mm (calf segment simulation) |
| Sample Clamping | Adjustable vacuum chuck (5–50 N grip force) |
| Data Output | Pressure-time curve and CSV export |
| Power Supply | 220V/50Hz, 0.8 kW |
| Dimensions (L×W×H) | 600×400×800 mm |
