Textile moisture absorption and heat generation performance tester
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
Application
This instrument is suitable for measuring the moisture-absorption-induced heat generation of various textile materials. It is commonly used for:
Functional thermal underwear
Sports and outdoor performance fabrics
Fiber and yarn development evaluation
Fabrics with hygroscopic–exothermic treatments
Winter apparel and insulation materials
Bedding, mattress toppers, quilt fillings
Medical textiles requiring thermal response
Research and teaching in textile engineering
R&D of smart temperature-adaptive fabrics
It provides essential data for manufacturers, research institutes, inspection bodies, and textile laboratories requiring accurate moisture-induced thermal performance testing.
Standards
GB/T 29866-2013 – Test method for moisture absorption and heat generation performance of textiles
FZ/T 73036-2010 – Moisture absorption and heat-generating thermal underwear standard
Features
(1) High-precision thermal measurement
Fast-response sensors accurately capture temperature rise during moisture absorption.
(2) Controlled environmental simulation
Stable control of humidity, airflow, and temperature ensures repeatable test conditions.
(3) Multi-sample testing
Supports multi-channel testing (e.g., 4 channels) to improve laboratory efficiency.
(4) Stable and uniform chamber design
Optimized airflow and thermal insulation maintain consistent environmental conditions.
(5) User-friendly operation
Digital display, programmable test time, and intuitive interface ensure easy operation.
Parameters
| Parameter | Specification |
|---|---|
| Temperature Rise Range | 0–100 °C |
| Temperature Resolution | 0.01 °C |
| Temperature Fluctuation | ≤ ±0.5 °C |
| Relative Humidity Range | 30%–90% ± 3% |
| Air Velocity | 0.3–0.5 m/s (adjustable) |
| Test Time Range | 0 min 01 s – 99 min 59 s |
| Time Resolution | 1 second |
| Detection Channels | 4 channels |
| Chamber Size | 350 × 300 × 400 mm (W×D×H) |
| Chamber Material | Stainless steel with thermal insulation |
| Environmental Control System | Heating, humidification, refrigeration, air circulation |
| Power Supply | AC 220V / 50Hz |
Send product request
