Fabric Static Stress Resistance Tester
The fabric inductive electrostatic tester, under laboratory conditions, is suitable for determining the electrostatic properties of fibers, yarns, fabrics, carpets, decorative fabrics, and other types of fabrics or various sheet-like finished products. The main unit of the instrument consists of a corona discharge device and a probe detector. Using a given high-voltage electric field, the fabric is discharged for a fixed period of time, inducing static electricity.
Application
It is used for testing the elbow static stress deformation of textiles such as woven fabrics or knitted fabrics. The testing instrument includes an elbow fabric static stress resistance tester, an elbow fabric protrusion height measuring instrument, a sample preparation template, etc.
Standards
DIN 53860 - 1: Inspection of textiles - Inspection of planar fabric sac-like protrusions - Part 1: Static stress bend tube test method
Feature
1. The frame is made of high-quality aluminum alloy, which is relatively lightweight.
2. Equipped with LED lighting source, with high illuminance, clear imaging and easy identification.
3. Ball joint connection, with low sliding friction and smooth movement.
4. Hinged connection for easy clamping of samples.
5. The measuring arm is made of high-quality non-metallic materials, which is light and easy to operate.
Parameters
| Parameter | Description |
|---|---|
| Angle of the upper test arm relative to the vertical line | 10 degrees |
| Spring stiffness | 149N/M (meeting the standard requirement of 150N/M ± 30N/M) |
| Wire diameter | 0.3mm |
| Diameter | 3mm |
| Length of the upper test arm | 250mm |
| Length of the lower test arm | 300mm |
| Connection method | Ball joint connection |
| Lighting source | LED with a power of 20W |
| Projection method | Optical imaging with a resolution of 1mm |
| Measuring arm | Hinged connection for easy clamping of samples |
| Dimensions - Static stress experiment part | 600mm×600mm×800mm |
| Dimensions - Projection measurement part | 400×600×600mm |
| Power supply | AC220V 50Hz |
