Horizontal Vertical Combustion Tester
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
Horizontal and vertical combustion tester is mainly used for measuring the burning performance of plastic, rubber or film at a predetermined fire source, to determine its fire resistance rating. It can be applied not only for the research, production and quality control departments of lighting, low-voltage electrical appliances, household appliances, electrical machine, tools, instruments as well as electrical connections and other electrical and electronic plastic or rubber products and component parts, but also for the type approval of insulation, plastic , fire blocking material or other solid combustible materials industry.
Standards
UL94:Test for flammability of plastic materials for parts in devices and appliances
ISO 1210:Plastics -- Determination of the burning behaviour of horizontal and vertical specimen
GB/T2408-2008/IEC:1999:Plastics-Determination of burning characteristics- Horizontal and vertical test
GB/T 5169.16-2008/IEC :2003/ASTM D635 Fire hazard testing for electric and electronic products. Part 16:Test flames. 50W horizontal and vertical flame test methods
GB/T 8332-2008/ISO 9772-2001/ASTM D 4986:Test method for flammability of cellular plastic-Horizonal burning method
ASTM D4804 /ISO 9773:Standard test method for determining the flammability characteristics of non-rigid solid plastics
Features
◆The ultra - large transparent observation window makes it easy to observe the burning state of the specimen;
◆Humanized design of the door opening way. It is an easy way to touch the sample and burner;
◆PLC touch screen control is easy to set parameters;
◆Different test methods modular is easy to operate;
Technical Parameters
| Items | Parameters |
| Inter Size | 850mm×600mm×1000mm |
| Vent (above) | Φ135mm×85mm |
| Burning angle | 45 °，90 ° （0 °） Adjustable |
| The specimen holder can be moved horizontally vertically | |
| Flame time | 5s, 10s, 30s, 60s optional |
| Combustion timer | Timer (accurate to 0.1s) |
| Burner | Length 100 ±10 mm, Inner diameter 9.5 ±mm 0.3. ASTM D 5025 |
| Outline size | 1200mm * 620mm * 1300mm |
| Weight | 90kg |
| Power supply | 220V, 50Hz |
