Needle Flame Tester

Application

The needle flame tester is widely used in various fields, including but not limited to the following applications:

Electrical and electronic equipment: Used to evaluate the flame retardant performance of electrical and electronic products, ensuring the safety of equipment under abnormal conditions.

Household appliances: Used to test the flame retardant performance of materials inside household appliances, ensuring home safety.

Building materials: Used to evaluate the flame retardant performance of building materials, ensuring the safety of building structures.

Automotive interior parts: Used to evaluate the flame retardant performance of automotive interior parts, ensuring safety inside the vehicle.

Aerospace materials: Used to evaluate the flame retardant performance of aerospace materials, ensuring flight safety.

The needle flame tester assesses the flammability risk of materials by simulating small flames under fault conditions. It complies with international and domestic standards and is an important tool for improving product fire safety performance and ensuring personal and property safety.

Standard

GB/T 5169.5: Electrical & Electronic Equipment – Needle Flame Test Method

IEC 60695-11-5/IEC 60695-2-2: Fire Hazard Testing – Needle Flame Test Apparatus

IEC 60745-1/IEC 60335-1: Safety of Handheld Motor-Operated Tools & Household Appliances

IEC 60950-1/IEC 60598-1/IEC 60065: IT Equipment, Luminaires, & Audio/Video Safety

Technical Parameters

ParameterSpecification
Burner Specs Stainless Steel; Inner Φ0.5±0.1mm; Outer Φ0.9mm; Length >35 mm
Flame Angle Vertical (Calibration) / 45° (Test)
Combustion Gas 95% Butane/Propane
Flame Temperature 100–700°C (Rise Time: 23.5±1.0s)
Test Time 0–999.9s (Adjustable; Default: 30s)
Burning Time Recording 0–9999s (Automatic)
Chamber Volume >0.5 m³ (900×590×1050 mm); Custom Options: 0.75/1 m³
Exhaust Pipe Φ100 mm
Control System PLC + 7-inch Touchscreen
Dimensions (W×D×H) 1120 × 520 × 1250 mm
Net Weight 80 kg
Power Supply AC 220V ±10%, 50Hz
Temperature Range

0–1000°C (K-Type Thermocouple)
