Thermal Protective Performance Tester
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
Application:
The thermal protection performance (TPP) tester is mainly used to test the thermal insulation properties of horizontally placed flame retardant protective clothing fabrics exposed to radiant and convective heat sources.measuring the resulting damage to human skin.
Standards
(1) BS EN ISO 6942 – Protective clothing – Protection against heat and flame – Method of test for the determination of heat transfer on exposure to a heat source
(2) EN 366 – Protective clothing against heat and flame – Resistance of materials to contact heat
(3) EN 407 – Protective gloves against thermal risks (heat and/or fire)
(4) ISO 11612 – Protective clothing – Clothing to protect against heat and flame
(5) ASTM F1939 – Standard Test Method for Evaluation of Thermal Protective Performance of Materials for Clothing
(6) ASTM F2702 – Standard Test Method for Heat Transfer and Thermal Protective Performance of Flame Resistant Clothing Materials Using a Thermal Protective Performance Tester
(7) NFPA 1971 – Standard on Protective Ensembles for Structural Fire Fighting and Proximity Fire Fighting
(8) NFPA 2112 – Standard on Flame-Resistant Garments for Protection of Industrial Personnel Against Flash Fire
(9) GB 38543 – Technical Specification for Fire Protection of Workwear for Industrial Personnel
(10) GB/T 38306 – Test Method for Thermal Protective Performance of Flame Retardant Protective Clothing
Technical Parameters
| Heat Flux Measurement Range | 0–167 kW/m² |
| Heat Flux Measurement Accuracy | ±2 kW/m² |
| Specimen Irradiated Size | ≥200mm*200mm,for testing flame-retardant protective clothing, fire-fighting suits and protective gloves |
| ConvectionHeatSource | 2Merkel lamps (Heat flux: up to 60 kW/m²; Radiant heat flux: up to 40 kW/m²) |
| Rotor Propane Gas Flowmeter | Provides precise, stable propane flow for the burner |
| Radiant Heat Source | 9pcs of500W infrared quartz lamps (proportional power controlfor0–30 kW/m²radiant heat flux) |
| ASTM F2703Copper Calorimeter | Accuracy±3% F.S.;Weight 1000±10 g |
| Copper Calorimeter Copper Plate | Imported Oxygen-Freesuperconductingcopper |
| Data Acquisition System Sampling Rate | ≥20samples/second |
| Environment | 15–35℃ |
| Fume Hood | Recommended internal dimensions ≥150×75×90 cm, including door height |
| Gas Source | Propane (Purity≥95%, equipped with pressure reducing valve - cylinder & outlet pressure controlled) |
| Compressed Air | Customer-supplied |
| Cooling Water Source | Tap water (inlet & outlet) or optional chiller |
| Power supply | Single phaseAC220V 50Hz |
| Dimension | 130×65×53cm (LXWXH) |
| Weight | Around 60kg |
