7.5kW Super Xenon Weather Meter
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
7.5kW Super Xenon Weather Meter is designed to artificially replicate indoor and outdoor environments—such as sunlight, temperature, humidity, and rainfall—to accelerate the aging of products and materials, thereby predicting their service life.
This model delivers irradiation levels up to three times that of solar ultraviolet light (180W/m²), meeting the demands of today's rapidly evolving products.
Standards
ISO 4892-2: Plastics—Methods of exposure to laboratory light sources (Xenon-arc lamps).
ASTM G155: Standard Practice for Operating Xenon Arc Light Apparatus for Exposure of Nonmetallic Materials.
SAE J2527 / J2412: Performance-based exposure of automotive exterior and interior trim using a controlled irradiance xenon-arc apparatus.
JIS D0205: Test of weatherability for automobile parts.
JASO M346: Light-exposure test method for automotive interior parts.
AATCC TM16.3: Colorfastness to light (Xenon-Arc).
GB/T 16422.2: Plastics—Methods of exposure to laboratory light sources—Part 2: Xenon-arc lamps.
Parameters
|
Light source |
One 7.5-kW water-cooled xenon arc lamp |
|
Test types |
Light only,Light&Spray on front face(Rain),Dark only,Dark&Spray on back face(Dew),Dark&Spray on both faces |
|
Irradiance |
60 W/㎡to 180W/㎡ at 300nm to 400nm (Filter requirement example;quartz inner filter and#295 outer filter) |
|
Temperature and humidity range |
Light test:50℃to 95℃±1℃of black panel temperature(BPT;depending on the level of irradiance); 50%rh to 60%rh±5%rh(at 63℃of BPT and 180W/㎡) |
|
Dark test:38℃±1℃of chamber temperature; 95%rh±5%rh |
|
|
Quantity of specimen |
Maximum 54 pieces(Specimen size:150mm x70mm,1mm thick) |
|
Electrical requirements |
Three-phase,200V,approx.74A |
|
External dimension |
Approx.Width 105cm,Depth 135cm,and height 204cm (Weight:approx.570kg) |
|
Related standards |
ISO,ASTM,SAE,JIS,and JASO(subject to different accessories) Simultaneous BPT and CT control(SAE)available. |
