Fogging Tester
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
Application
1. Evaluating Material Fogging Performance
The fogging tester is primarily used to evaluate the evaporation of volatile components from interior materials of automobiles, aircraft, and other vehicles at high temperatures. These interior materials include plastic parts, polyurethane, textiles, leather, adhesives, non-woven fabrics, and thermoplastic elastomers. The test reveals the generation of volatile substances from the materials at high temperatures, thus determining their fogging performance.
2. VOC Detection
This instrument is one of the essential instruments for VOC (Volatile Organic Compounds) detection in the automotive interior industry. The test provides evaporation data of volatile substances from interior materials at high temperatures, providing important information for controlling indoor air pollution and ensuring the health of drivers and passengers.
3. Screening Environmentally Friendly Materials
Through testing with the fogging tester, environmentally friendly interior materials that meet environmental standards can be selected, helping automobile manufacturers improve the market competitiveness of their products while reducing environmental pollution.
Standard Test
DIN 75201: Automotive trim material fogging resistance.
ISO 6452: Coated fabrics fogging behavior in vehicle interiors.
SAE J1756: Automotive interior material fogging test protocol.
BS EN 14288 & QB/T 2728: Leather and textile fogging evaluation.
PV 3920/3015: VDA-standard fog value determination for non-metallic materials.
ES-X83231. NES M0161. GM 9305P: OEM-specific fogging requirements for automotive suppliers.
Parameters
| Parameter | Specification |
|---|---|
| High-Temperature Range | Room temperature – 150°C (280°C optional) |
| Low-Temperature Range | 0–100°C |
| Temperature Stability | ±0.1°C (at 200°C) |
| Heat-Up Time | |
| Cooling Capacity | 500W (low bath) |
| Power Supply | AC 220V, 50Hz, 3.5kW |
| Dimensions | 500 (W) × 650 (D) × 600 (H) mm |
| Net Weight | 50 kg (excluding thermal media) |
| Data Interface | USB 2.0. remote sensor compatibility |
| Safety Systems | Magnetic switch, thermostat, audible alerts |
