Flame Penetration Fuel Test System for Thermal and Acoustic Insulation Materials
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
The Flame Penetration Fuel Test System for Thermal and Acoustic Insulation Materials is a dedicated fire testing platform designed to evaluate flame penetration behavior, combustion performance, and thermal response of aerospace insulation materials under controlled aviation fuel fire exposure. The system integrates the FAA-approved NexGen aviation fuel burner with a specialized flame penetration test apparatus and a dynamic loading motion system, enabling realistic simulation of aircraft fire scenarios while accurately controlling and monitoring fuel and air parameters. The modular design supports both current testing requirements and future FAA technical upgrades.
Parameters
| Item | Specification |
|---|---|
| Overall dimensions | 1500 mm (W) × 1800 mm (H) × 900 mm |
| System weight | 150 kg |
| Power requirement | 220 V, 10 A |
| Operating temperature | 10°C to 35°C |
| Fuel type | Aviation kerosene |
| Air supply | Minimum 120 PSI compressed air |
| Flame temperature capability | ≥ 2000 ± 50 ℉ |
| Heat flux output | ≥ 10.6 W/cm² |
| Temperature control bath | ≥ 2 × 0.14 m³ |
Send product request
