Filter Media Tester G505
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
The Filter Media Dynamic Filtration Performance Tester is primarily used to assess the filtration performance of filter media. This equipment is user-friendly, compact, and robust in design. It allows for quick and convenient adjustment of dust concentration values during filtration tests, with a high degree of simulation of actual conditions. After testing, the digital system of a light scattering spectrometer measures particle size and concentration online.
Standards
GB/T6719-2009 :Technical requirements for bag dust collectors
ISO 11057-2011 :Filter performance test of cleanable filter media
VDI 3926-2004 :Filter performance test of cleanable filter media
ASTM D6830 :Standard Test Method for Characterizing the Pressure Drop and Filtration Performance of Cleanable Filter Media
VDI/DIN 3926: Testing of cleanable filter media Standard test for the evaluation of cleanable filter media
GB/T 6719: Specifications for bag house
JIS Z8909-1: Test method of filter media for dust collection Part 1:Filter efficiency
DIN 71460-1:Road vehicles - Air filters for motor passenger compartments - Part 1: Test for particulate filtration
ISO 11 155-1:Road vehicles — Air filters for passenger compartments — Part 1: Test methods for particulate air filters
VDI 3926-II:esting of cleanable filter media - Part 2: Static filtration performance test
EN 779:Particulate air filters for general ventilation — Determination of the filtration performance
Parameters
| Item | Technical Parameter |
|---|---|
| Particle type | Non-sticky dry powder |
| Continuous operation time | 1–50 h |
| Compressed air requirement | ≤ 6 bar |
| Dust mass flow | 0.05–20 g/h, continuously adjustable, stability ≤ 5% |
| Aerosol outlet mass concentration | 0.012–13 g/h |
| Power supply | 100–260 VAC, 47–63 Hz |
| Filter test area | 140 mm diameter |
| Filter face velocity | 1–3 m/min, adjustable |
| Horizontal pipe flow | 0–3 m³/h |
| Bypass pipe | Extensible |
| Pressure sensor range | 0–2000 Pa |
| Pressure sensor accuracy | ±2% |
| Backflush pressure | 0.2–0.6 MPa, adjustable |
| Backflush time | 50–200 ms, adjustable |
| Pulse valve control | Time-controlled and pressure-controlled |
| Suction flow controller | Mass flow meter 80 LPM, accuracy 0.1 LPM |
| Dust dispersion air control | Mass flow meter 20 LPM, accuracy 0.1 LPM |
| Vacuum pump | 8 m³/h, 4 × 10⁻⁴ mbar, 550 W |
| Control software | Pressure signal sampling (A/B/C/D), constant-pressure injection, aging control |
| Test modes | Manual, semi-automatic, automatic |
| Data processing mode | NEU data processing mode |
