Vacuum Cleaner Filtration Test System
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
Vacuum Cleaner Filters for emission characterisation of vacuum cleaners (EN 60312)
For emission tests the suction air is prepared with a dust concentration of 550 mg/m³ and passed directly into the hose of the vac.
For dust retaining tests the suction air is prepared with a dust concentration of 100 mg/m³ in the inlet channel (mixingtube) described in the standard.
Applications
Determination ofparticleemission of the vacuum cleaner into the exhaust air
Determination of the dust retaining capacity of the vacuum cleaner
Standard
The Vacuum Cleaner Filters is designed for tests on vacuum cleaners (vac) for household or small business use according to the standard EN 60312.
GB/T 38043-2019 Commercial Vacuum Cleaner Performance Test Methods
GB/T 4214.2-2020 Noise Measurement for Household Appliances – Vacuum Cleaner Requirements
EN 60312 Vacuum Cleaner Performance Test Standard
Commission Delegated Regulation (EU) No. 665/2013 Energy Label and Dust Re-Emission Requirements
Features
Manual control for service, calibration procedures and user defined tests
Automatic test procedures in accordance with standard EN 60312
Emission test with determination of the average result and determination of a confidence limit
Filtration efficiencytest with determination of a confidence limit
Dust-reemission tests according to Commission Delegated Regulation (EU) No. 665 / 2013; known as ‘Energy Label for Vacuum Cleaners’
Technical data
| Parameter title | Unit | Value |
|---|---|---|
| test flow rate | m³/h | 18 ... 200 |
| power supply | - | 230 V AC; 50-60 Hz; 16 A |
| operating medium, gas/air | - | dry,particle-free compressed air |
| operating medium, gas/air - compressed air supply | bar | min. 5 (min. 5 m³/h) |
| dimensions (w × h × d) | mm | 2600 ×2500 × 850 |
| weight | kg | 350 |
