Burning Manikin System
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
The Burning Manikin System is primarily applied in the following areas:
Fire Environment Simulation: This system simulates high-risk fire environments, realistically recreating flashover scenarios. Using a burning manikin testing system and accompanying software, it evaluates the flame-retardant performance of protective clothing.
Thermal Protection Performance Assessment: By placing thermal sensors on the manikin model, it measures and calculates the heat and temperature transmitted through the clothing to various parts of the manikin's surface, thereby predicting the possible locations and extent of burns.
Fire Environment Research: This system helps researchers analyze the heat transfer mechanism between the heat source, clothing, and the human body in a fire environment, improving the thermal protection performance of protective clothing.
Firefighter Protection: Through burning manikin testing, it evaluates the heat insulation performance of fire suits, optimizing designs to reduce the rate of burns.
These applications contribute to improving the survivability of firefighters and soldiers under high-intensity flame conditions.
Standards
EN ISO 11612：rotective clothing - Clothing to protect against heat and flame - Minimum performance requirements
EN ISO 11611：Protective clothing for use in welding and allied processes - Minimum basic safety requirements
ISO 13506：Protective clothing against heat and flame - Test method for complete garments - Prediction of burn injury using an instrumented manikin
EN469:2005：Protective clothing for firefighters - Performance requirements for protective clothing for firefighting
ISO13506-1：Protective clothing against heat and flame- part1: Test method for complete garments-Measurement of transferred energy using an instrumented manikin
ISO13506-2：Protective clothing against heat and flame- part2: Skin burn injury prediction- Calculation requirements and test cases
ASTM F1930：Standard test method for evaluation of flame-resistant clothing for protection against fire simulations using an instrumented manikin
GB8965.1：Protective clothing - Flame retardant protective clothing
Parameters
| Parameter | Description |
| Dimensions (L×W×H) | 14m × 6m × ≥6m |
| Weight | 2000 kg |
| Thermal Sensors | Monitor heat flux changes on mannequin surface; quantity varies by design |
| Combustion Flame Array | Multiple propane generators arranged around mannequin to simulate fire |
| Gas Supply System | Provides stable gas via high-pressure tanks and pipelines |
| Combustion Chamber | Houses flame array and mannequin for safe, controlled experiments |
| Data Acquisition System | Collects data from thermal sensors with processing units and cables |
| Testing Software | Controls experiments, analyzes data, and generates visual reports |
| Calibration Tools | Ensure accuracy and reliability of sensor data through calibration |
