380V industrial rain test chamber
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
Detailed Product Description STANDARD Comprehensive Rain Test Box Spray Ring Radius: 235 (mm) Water Pipe Diameter: Φ600mm Nozzle Diameter: Φ0.4mm Aperture Spacing 50mm: Aperture Spacing 50mm Standard: IPX1-6BS-R400 Highlight: environmental testing equipment environmental testing machine 380V Comprehensive Rain Test Box Full Water Spray Test Effect Equipment features STD IPX1-IPX6 can be completed; Sample energization test; Full water spray test effect; Three screen integrated control (APP+ PC); MainTechnical Parameters Model SL-IPX1-6BS-R400 Inner dimension 900×900×900mm Outer dimension 1350×3500×1900mm Rain drop area 600×600mm Size of swing tube R400mm can add R200mm IPX3/4Flow IPX3=1.8L/min; IPX4=2.6L/min IPX5/6 Lance diameter φ6.3mm(IPX5) ; φ12.5mm(IPX6) IPX5/6 Flow 12.5L±0.625/min(IPX5) ; 100±5L/min(XPX6) Turntable speed 1-5r/min Adjustable Turntable diameter φ600mm Elevating height of turntable 550-1100mm Spray gun mode Automatic sweeping up and down Power supply voltage 380V
Send product request
