Rotary rheometer
Get a quote：
Whats/App: +86 185 0176 3615
Web: qinsun-lab.com
Rotary rheometer is a rotational rheometer based on state-of-the-art technologies also used in R&D rheometers. It combines unrivaled performance with easy operation and robust design. From quick single-point checks over flow curve and yield point determinations to complex rheological investigations: Rotary rheometer sets new standards for carrying out routine rheological tests.
Standards：
DIN 1342 1-3、3219、53019-1、53019-2;
EN 3219;
ISO 3219;
European Pharmacopoeia (Ph. Eur.)
2.2.8. Viscosity
2.2.10. Viscosity - Rotating viscometer method
US Pharmacopoeia (USP)
912 - Viscosity - Rotational Methods
IOCCC 2000;
CFR 21 Part 11;
Specifications：
| Property | Range |
| Speed | 0.01 1/min to 1200 1/min |
| Torque | 0.20 mNm to 75 mNm |
| Shear stress | 0.5 Pa to 3 x 104 Pa |
| Shear rate | 10-2 1/s to 6500 1/s |
| Viscosity range | 1 mPa.s to 109 mPa.s |
| (depending on the measuring system) | |
| Temperature range | -20 °C to +180 °C |
| Angular resolution | 2 µrad |
| Physical variables (measurement or evaluation) | Speed |
| Torque | |
| Shear rate | |
| Shear stress | |
| Dynamic viscosity | |
| Temperature | |
| Time | |
| Deformation | |
| Compliance | |
| Yield stress | |
| Flow and viscosity curve | |
| Thixotropy | |
| Time and temperature test | |
