Carton drop tester

Get a quote:

Whats/App: +86 185 0176 3615

Web: qinsun-lab.com

The Carton Drop Tester is designed to simulate the impact experienced by packaging during transportation, handling, and loading/unloading. It evaluates the impact strength of packages, the durability of materials, and the rationality of packaging design by performing controlled free-fall drops.

Applications

This tester is widely used in the packaging, logistics, electronics, food, pharmaceutical, and e-commerce industries. It is suitable for manufacturers of corrugated cartons, boxes, and transport packaging to ensure product protection and optimize packaging design.

Standards

The Carton Drop Tester meets the following international and national standards:

ISO 2248 – Packaging — Transport packages — Vertical impact test by dropping

GB/T 4857-5 – Packaging — Transport packages — Vertical impact test by dropping

ASTM D5276 – Standard test method for drop test of loaded containers by free fall

ISTA 1A, 2A, 3A – International Safe Transit Association protocols

ASTM 4619 – Standard test methods for packages

IEC 60068-2-31 – Environmental testing — Drop test

JIS Z0202 – Japanese Industrial Standard for package drop testing

EN 438-2.21 – High-pressure decorative laminates — Determination of impact resistance

Technical Parameters

ParameterSpecification
Drop height 300–1500 mm (adjustable)
Maximum sample weight 70 kg
Maximum sample size 800 × 800 × 800 mm
Impact panel size 1700 × 1200 × 14 mm
Motor power 1.85 kW
Overall dimensions (L × W × H) 1700 × 1200 × 2350 mm
Net weight ~600 kg
Power supply AC 380 V, 50 Hz
Control Motorized and pneumatic lifting, wired remote control
Drop test modes Surface, edge, corner
